Test Date: 2016-11-14 10:58
Analysis date: 2016-11-14 11:46
Analysis date: 2016-11-14 11:46
M1127 XRayHRQualification
Summary
| Module | Module | M1127 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 2 | |
| BumpBondingDefects | Bump Bonding Defects | 2 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.56 | % |
| Noise | Mean Noise | 378 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.81 | 99.50 | 0.32 | 214.7 | 2 | 72.2 | 0/0 | 0 | 3681 | 378 | 1484 |
|
Chip 1
|
A
|
0 | 0 | 99.81 | 99.59 | 0.24 | 193.5 | 0 | 63.8 | 0/0 | 0 | 3720 | 342 | 932 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.51 | 0.26 | 226.0 | 0 | 75.8 | 0/0 | 0 | 3686 | 351 | 1043 |
|
Chip 3
|
A
|
0 | 0 | 99.83 | 99.63 | 0.24 | 181.8 | 0 | 60.1 | 0/0 | 0 | 3723 | 345 | 970 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.56 | 0.2 | 166.5 | 0 | 56.8 | 0/0 | 0 | 3726 | 348 | 1012 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.60 | 0.25 | 238.4 | 0 | 78.9 | 0/0 | 0 | 3631 | 372 | 1366 |
|
Chip 6
|
A
|
1 | 0 | 99.81 | 99.52 | 0.23 | 269.7 | 1 | 90.5 | 0/0 | 0 | 3581 | 395 | 1678 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.57 | 0.4 | 292.6 | 0 | 98.0 | 0/0 | 0 | 3600 | 405 | 1842 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.53 | 0.35 | 340.7 | 0 | 113.6 | 0/0 | 0 | 3542 | 431 | 2149 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.55 | 0.37 | 278.3 | 0 | 92.5 | 0/0 | 0 | 3604 | 389 | 1628 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 99.57 | 0.38 | 253.6 | 0 | 84.0 | 0/0 | 0 | 3588 | 394 | 1719 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.55 | 0.24 | 214.2 | 0 | 71.3 | 0/0 | 0 | 3535 | 408 | 1945 |
|
Chip 12
|
A
|
0 | 0 | 99.83 | 99.50 | 0.22 | 164.9 | 0 | 54.8 | 0/0 | 0 | 3658 | 351 | 1037 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 99.58 | 0.35 | 252.3 | 0 | 83.7 | 0/0 | 0 | 3562 | 408 | 1863 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 99.58 | 0.17 | 218.3 | 0 | 72.7 | 0/0 | 0 | 3677 | 355 | 1088 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.57 | 0.23 | 261.3 | 0 | 86.7 | 0/0 | 0 | 3684 | 378 | 1466 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-14 | |
| TestTime | Test Time | 10:58 | |
| TestDuration | Duration | 0:37:17 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
v1.1.1-1-g54fa876 on branch master
