Test Date: 2016-11-14 10:58
Analysis date: 2016-11-14 11:41
Analysis date: 2016-11-14 11:41
M1126 XRayHRQualification
Summary
| Module | Module | M1126 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 5 | |
| BumpBondingDefects | Bump Bonding Defects | 5 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.56 | % |
| Noise | Mean Noise | 362 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.82 | 99.56 | 0.32 | 203.3 | 0 | 65.2 | 0/0 | 0 | 3681 | 341 | 867 |
|
Chip 1
|
A
|
0 | 0 | 99.80 | 99.51 | 0.35 | 240.2 | 0 | 77.0 | 0/0 | 0 | 3584 | 414 | 1974 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.60 | 0.31 | 172.4 | 0 | 55.9 | 0/0 | 0 | 3716 | 347 | 941 |
|
Chip 3
|
A
|
1 | 0 | 99.81 | 99.56 | 0.32 | 162.5 | 1 | 53.7 | 0/0 | 0 | 3619 | 403 | 1823 |
|
Chip 4
|
A
|
2 | 0 | 99.81 | 99.45 | 0.27 | 130.2 | 2 | 43.0 | 0/0 | 0 | 3712 | 339 | 818 |
|
Chip 5
|
A
|
1 | 0 | 99.82 | 99.60 | 0.32 | 192.2 | 1 | 62.7 | 0/0 | 0 | 3657 | 375 | 1445 |
|
Chip 6
|
A
|
0 | 0 | 99.81 | 99.48 | 0.23 | 141.8 | 0 | 46.4 | 0/0 | 0 | 3724 | 341 | 900 |
|
Chip 7
|
A
|
1 | 0 | 99.80 | 99.62 | 0.27 | 146.8 | 1 | 48.0 | 0/0 | 0 | 3687 | 362 | 1157 |
|
Chip 8
|
A
|
0 | 0 | 99.79 | 99.63 | 0.2 | 146.3 | 0 | 47.8 | 0/0 | 0 | 3725 | 335 | 769 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.76 | 0.17 | 139.3 | 0 | 45.6 | 0/0 | 0 | 3675 | 373 | 1362 |
|
Chip 10
|
A
|
0 | 0 | 99.84 | 99.43 | 0.3 | 175.5 | 0 | 56.8 | 0/0 | 0 | 3608 | 401 | 1776 |
|
Chip 11
|
A
|
0 | 0 | 99.80 | 99.61 | 0.22 | 132.7 | 0 | 43.3 | 0/0 | 0 | 3707 | 344 | 935 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.48 | 0.24 | 122.8 | 0 | 40.5 | 0/0 | 0 | 3748 | 335 | 875 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.57 | 0.27 | 189.2 | 0 | 61.2 | 0/0 | 0 | 3699 | 345 | 962 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 99.62 | 0.25 | 170.3 | 0 | 55.0 | 0/0 | 0 | 3676 | 364 | 1181 |
|
Chip 15
|
A
|
0 | 0 | 99.84 | 99.55 | 0.35 | 249.2 | 0 | 80.1 | 0/0 | 0 | 3654 | 371 | 1324 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-14 | |
| TestTime | Test Time | 10:58 | |
| TestDuration | Duration | 0:37:17 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 15 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
v1.1.1-1-g54fa876 on branch master
