Test Date: 2016-11-07 13:44
Analysis date: 2016-11-07 15:58
Analysis date: 2016-11-07 15:58
M1123 XRayHRQualification
Summary
| Module | Module | M1123 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 2 | |
| BumpBondingDefects | Bump Bonding Defects | 2 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.59 | % |
| Noise | Mean Noise | 327 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.81 | 99.55 | 0.36 | 296.6 | 1 | 96.9 | 0/0 | 0 | 3785 | 356 | 1213 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.58 | 0.31 | 282.7 | 0 | 91.3 | 0/0 | 0 | 3748 | 376 | 1455 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.57 | 0.27 | 252.2 | 0 | 81.5 | 0/0 | 0 | 3805 | 330 | 864 |
|
Chip 3
|
A
|
0 | 0 | 99.80 | 99.47 | 0.33 | 159.3 | 0 | 52.4 | 0/0 | 0 | 3816 | 314 | 562 |
|
Chip 4
|
A
|
0 | 0 | 99.81 | 99.58 | 0.27 | 146.6 | 0 | 49.0 | 0/0 | 0 | 3845 | 317 | 607 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.55 | 0.22 | 196.3 | 0 | 65.2 | 0/0 | 0 | 3784 | 338 | 930 |
|
Chip 6
|
A
|
0 | 0 | 99.80 | 99.70 | 0.24 | 168.6 | 0 | 56.1 | 0/0 | 0 | 3824 | 328 | 792 |
|
Chip 7
|
A
|
1 | 0 | 99.83 | 99.91 | 0.21 | 148.4 | 1 | 48.8 | 0/0 | 0 | 3861 | 311 | 535 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.57 | 0.26 | 167.0 | 0 | 54.8 | 0/0 | 0 | 3832 | 331 | 774 |
|
Chip 9
|
A
|
0 | 0 | 99.83 | 99.78 | 0.19 | 159.1 | 0 | 52.6 | 0/0 | 0 | 3847 | 307 | 532 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 99.46 | 0.21 | 163.3 | 0 | 54.4 | 0/0 | 0 | 3772 | 292 | 359 |
|
Chip 11
|
A
|
0 | 0 | 99.84 | 99.49 | 0.2 | 132.4 | 0 | 44.2 | 0/0 | 0 | 3849 | 295 | 403 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.63 | 0.24 | 155.3 | 0 | 51.3 | 0/0 | 0 | 3847 | 303 | 492 |
|
Chip 13
|
A
|
0 | 0 | 99.80 | 99.47 | 0.32 | 235.5 | 0 | 77.7 | 0/0 | 0 | 3768 | 331 | 809 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 99.57 | 0.28 | 227.1 | 0 | 74.4 | 0/0 | 0 | 3758 | 330 | 857 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.57 | 0.4 | 275.7 | 0 | 89.2 | 0/0 | 0 | 3762 | 372 | 1415 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-07 | |
| TestTime | Test Time | 13:44 | |
| TestDuration | Duration | 0:59:5 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
v1.1.1-1-g54fa876 on branch master
