Test Date: 2016-11-08 10:22
Analysis date: 2016-11-08 11:37
Analysis date: 2016-11-08 11:37
M1117 XRayHRQualification
Summary
| Module | Module | M1117 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 8 | |
| BumpBondingDefects | Bump Bonding Defects | 8 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.80/99.53 | % |
| Noise | Mean Noise | 408 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.55 | 0.33 | 212.9 | 0 | 70.5 | 0/0 | 0 | 3507 | 420 | 2094 |
|
Chip 1
|
A
|
0 | 0 | 99.81 | 99.57 | 0.38 | 216.0 | 0 | 71.6 | 0/0 | 0 | 3565 | 406 | 1858 |
|
Chip 2
|
A
|
7 | 0 | 99.80 | 99.55 | 0.24 | 233.2 | 7 | 78.3 | 0/0 | 0 | 3519 | 429 | 2185 |
|
Chip 3
|
A
|
0 | 0 | 99.80 | 99.55 | 0.2 | 162.7 | 0 | 54.3 | 0/0 | 0 | 3635 | 388 | 1588 |
|
Chip 4
|
A
|
0 | 0 | 99.80 | 99.55 | 0.26 | 170.3 | 0 | 57.0 | 0/0 | 0 | 3642 | 381 | 1548 |
|
Chip 5
|
A
|
0 | 0 | 99.81 | 99.57 | 0.34 | 236.3 | 0 | 78.3 | 0/0 | 0 | 3526 | 424 | 2120 |
|
Chip 6
|
A
|
0 | 0 | 99.81 | 99.50 | 0.27 | 200.1 | 0 | 66.4 | 0/0 | 0 | 3395 | 396 | 1709 |
|
Chip 7
|
A
|
0 | 0 | 99.80 | 99.52 | 0.38 | 269.7 | 0 | 88.4 | 0/0 | 0 | 3485 | 435 | 2249 |
|
Chip 8
|
A
|
0 | 0 | 99.82 | 99.56 | 0.27 | 241.9 | 0 | 79.3 | 0/0 | 0 | 3653 | 391 | 1660 |
|
Chip 9
|
A
|
0 | 0 | 99.78 | 99.48 | 0.82 | 265.6 | 0 | 88.8 | 0/0 | 0 | 3595 | 411 | 1930 |
|
Chip 10
|
A
|
0 | 0 | 99.79 | 99.48 | 0.33 | 262.4 | 0 | 86.8 | 0/0 | 0 | 3513 | 421 | 2129 |
|
Chip 11
|
A
|
0 | 0 | 99.80 | 99.52 | 0.25 | 185.2 | 0 | 62.2 | 0/0 | 0 | 3544 | 399 | 1767 |
|
Chip 12
|
A
|
0 | 0 | 99.79 | 99.55 | 0.18 | 159.6 | 0 | 53.3 | 0/0 | 0 | 3556 | 409 | 1926 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 99.51 | 0.34 | 234.9 | 1 | 77.2 | 0/0 | 0 | 3482 | 412 | 1903 |
|
Chip 14
|
A
|
1 | 0 | 99.83 | 99.55 | 0.33 | 223.4 | 1 | 74.8 | 0/0 | 0 | 3498 | 407 | 1848 |
|
Chip 15
|
A
|
0 | 0 | 99.81 | 99.49 | 0.27 | 227.2 | 0 | 75.7 | 0/0 | 0 | 3585 | 406 | 1889 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-08 | |
| TestTime | Test Time | 10:22 | |
| TestDuration | Duration | 0:37:10 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
v1.1.1-1-g54fa876 on branch master
