Test Date: 2016-11-07 16:36
Analysis date: 2016-11-07 17:19
Analysis date: 2016-11-07 17:19
M1116 XRayHRQualification
Summary
| Module | Module | M1116 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.80/99.53 | % |
| Noise | Mean Noise | 397 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.79 | 99.60 | 0.28 | 211.9 | 0 | 71.1 | 0/0 | 0 | 3643 | 377 | 1399 |
|
Chip 1
|
A
|
1 | 0 | 99.81 | 99.44 | 0.23 | 200.8 | 1 | 66.6 | 0/0 | 0 | 3645 | 368 | 1287 |
|
Chip 2
|
A
|
2 | 0 | 99.81 | 99.50 | 0.23 | 216.2 | 0 | 71.6 | 0/0 | 0 | 3510 | 417 | 2046 |
|
Chip 3
|
A
|
0 | 0 | 99.80 | 99.56 | 0.29 | 164.0 | 0 | 55.1 | 0/0 | 0 | 3575 | 357 | 1123 |
|
Chip 4
|
A
|
0 | 0 | 99.80 | 99.61 | 0.23 | 171.2 | 0 | 57.4 | 0/0 | 0 | 3575 | 408 | 1874 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.55 | 0.35 | 245.1 | 0 | 81.1 | 0/0 | 0 | 3557 | 419 | 2011 |
|
Chip 6
|
A
|
0 | 0 | 99.80 | 99.54 | 0.28 | 258.9 | 0 | 86.0 | 0/0 | 0 | 3617 | 385 | 1550 |
|
Chip 7
|
A
|
0 | 0 | 99.81 | 99.54 | 0.36 | 257.1 | 0 | 85.8 | 0/0 | 0 | 3657 | 381 | 1502 |
|
Chip 8
|
A
|
0 | 0 | 99.80 | 99.57 | 0.26 | 231.8 | 0 | 76.5 | 0/0 | 0 | 3650 | 383 | 1517 |
|
Chip 9
|
A
|
0 | 0 | 99.79 | 99.57 | 0.46 | 247.9 | 0 | 80.9 | 0/0 | 0 | 3470 | 447 | 2406 |
|
Chip 10
|
A
|
0 | 0 | 99.80 | 99.51 | 0.28 | 244.7 | 0 | 82.0 | 0/0 | 0 | 3547 | 410 | 1897 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.58 | 0.18 | 154.2 | 0 | 50.6 | 0/0 | 0 | 3616 | 379 | 1475 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.52 | 0.23 | 150.4 | 0 | 50.3 | 0/0 | 0 | 3635 | 394 | 1689 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 99.48 | 0.3 | 224.1 | 0 | 74.5 | 0/0 | 0 | 3573 | 415 | 1965 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 99.51 | 0.31 | 203.8 | 0 | 68.3 | 0/0 | 0 | 3596 | 407 | 1868 |
|
Chip 15
|
A
|
0 | 0 | 99.79 | 99.45 | 0.27 | 207.2 | 0 | 68.6 | 0/0 | 0 | 3614 | 398 | 1740 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-07 | |
| TestTime | Test Time | 16:36 | |
| TestDuration | Duration | 0:36:56 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
v1.1.1-1-g54fa876 on branch master
