Test Date: 2016-11-04 16:23
Analysis date: 2016-11-04 17:50
Analysis date: 2016-11-04 17:50
M1115 XRayHRQualification
Summary
| Module | Module | M1115 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 2 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.55 | % |
| Noise | Mean Noise | 385 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.79 | 99.53 | 0.24 | 181.1 | 0 | 60.0 | 0/0 | 0 | 3467 | 380 | 1519 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.63 | 0.2 | 183.2 | 0 | 61.0 | 0/0 | 0 | 3645 | 381 | 1498 |
|
Chip 2
|
A
|
1 | 0 | 99.81 | 99.54 | 0.2 | 219.5 | 0 | 73.5 | 0/0 | 0 | 3614 | 395 | 1661 |
|
Chip 3
|
A
|
0 | 0 | 99.78 | 99.75 | 0.2 | 146.8 | 0 | 48.9 | 0/0 | 0 | 3709 | 326 | 715 |
|
Chip 4
|
A
|
0 | 0 | 99.79 | 99.47 | 0.32 | 138.3 | 0 | 46.6 | 0/0 | 0 | 3714 | 344 | 947 |
|
Chip 5
|
A
|
1 | 0 | 99.81 | 99.54 | 0.31 | 229.7 | 1 | 76.1 | 0/0 | 0 | 3632 | 399 | 1746 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 99.54 | 0.35 | 245.7 | 0 | 82.2 | 0/0 | 0 | 3679 | 374 | 1380 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.54 | 0.29 | 249.1 | 0 | 82.2 | 0/0 | 0 | 3662 | 387 | 1593 |
|
Chip 8
|
A
|
0 | 0 | 99.82 | 99.51 | 0.35 | 264.6 | 0 | 87.4 | 0/0 | 0 | 3585 | 407 | 1881 |
|
Chip 9
|
A
|
0 | 0 | 99.79 | 99.47 | 0.36 | 261.5 | 0 | 86.5 | 0/0 | 0 | 3598 | 419 | 2088 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.54 | 0.32 | 248.5 | 0 | 81.6 | 0/0 | 0 | 3376 | 384 | 1587 |
|
Chip 11
|
A
|
0 | 0 | 99.79 | 99.36 | 0.23 | 154.9 | 0 | 51.6 | 0/0 | 0 | 3714 | 364 | 1244 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.60 | 0.17 | 152.6 | 1 | 50.4 | 0/0 | 0 | 3648 | 379 | 1493 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.61 | 0.2 | 210.0 | 0 | 69.1 | 0/0 | 0 | 3588 | 414 | 1975 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 99.69 | 0.19 | 205.0 | 0 | 67.7 | 0/0 | 0 | 3594 | 415 | 1940 |
|
Chip 15
|
A
|
1 | 0 | 99.81 | 99.56 | 0.25 | 210.1 | 1 | 69.8 | 0/0 | 0 | 3636 | 398 | 1756 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-04 | |
| TestTime | Test Time | 16:23 | |
| TestDuration | Duration | 1:19:33 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
