Test Date: 2016-11-04 15:42
Analysis date: 2016-11-04 16:26
Analysis date: 2016-11-04 16:26
M1113 XRayHRQualification
Summary
| Module | Module | M1113 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 9 | |
| BumpBondingDefects | Bump Bonding Defects | 6 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.52 | % |
| Noise | Mean Noise | 385 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.45 | 0.26 | 215.0 | 0 | 71.8 | 0/0 | 0 | 3627 | 400 | 1783 |
|
Chip 1
|
A
|
0 | 0 | 99.81 | 99.56 | 0.25 | 225.4 | 0 | 75.5 | 0/0 | 0 | 3601 | 406 | 1866 |
|
Chip 2
|
A
|
0 | 0 | 99.81 | 99.57 | 0.27 | 233.6 | 0 | 77.8 | 0/0 | 0 | 3566 | 426 | 2144 |
|
Chip 3
|
A
|
0 | 0 | 99.82 | 99.54 | 0.25 | 164.8 | 0 | 55.1 | 0/0 | 0 | 3697 | 348 | 982 |
|
Chip 4
|
A
|
8 | 0 | 99.80 | 99.39 | 0.24 | 160.6 | 5 | 53.6 | 0/0 | 0 | 3667 | 376 | 1449 |
|
Chip 5
|
A
|
0 | 0 | 99.79 | 99.48 | 0.36 | 244.8 | 0 | 81.3 | 0/0 | 0 | 3547 | 411 | 1926 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 99.52 | 0.24 | 202.0 | 0 | 68.2 | 0/0 | 0 | 3679 | 366 | 1245 |
|
Chip 7
|
A
|
0 | 0 | 99.80 | 99.55 | 0.36 | 239.6 | 0 | 79.6 | 0/0 | 0 | 3604 | 384 | 1536 |
|
Chip 8
|
A
|
0 | 0 | 99.79 | 99.52 | 0.42 | 265.4 | 0 | 87.2 | 0/0 | 0 | 3708 | 344 | 1009 |
|
Chip 9
|
A
|
0 | 0 | 99.83 | 99.58 | 0.35 | 275.7 | 0 | 90.9 | 0/0 | 0 | 3479 | 401 | 1783 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.54 | 0.25 | 236.4 | 0 | 78.9 | 0/0 | 0 | 3684 | 369 | 1328 |
|
Chip 11
|
A
|
1 | 0 | 99.80 | 99.49 | 0.24 | 177.1 | 1 | 60.0 | 0/0 | 0 | 3659 | 362 | 1186 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 99.62 | 0.27 | 171.2 | 0 | 56.8 | 0/0 | 0 | 3687 | 362 | 1232 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 99.55 | 0.38 | 263.9 | 0 | 85.0 | 0/0 | 0 | 3599 | 398 | 1737 |
|
Chip 14
|
A
|
0 | 0 | 99.77 | 99.44 | 0.3 | 235.0 | 0 | 79.1 | 0/0 | 0 | 3601 | 394 | 1704 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.56 | 0.24 | 223.5 | 0 | 73.7 | 0/0 | 0 | 3556 | 413 | 1965 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-04 | |
| TestTime | Test Time | 15:42 | |
| TestDuration | Duration | 0:37:26 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
