Test Date: 2016-11-04 14:41
Analysis date: 2016-11-04 15:47
Analysis date: 2016-11-04 15:47
M1112 XRayHRQualification
Summary
| Module | Module | M1112 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/1/0 | |
| PixelDefects | Total Pixel Defects | 88 | |
| BumpBondingDefects | Bump Bonding Defects | 87 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.80/99.53 | % |
| Noise | Mean Noise | 388 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
29 | 0 | 99.81 | 99.50 | 0.43 | 265.0 | 32 | 86.7 | 0/0 | 0 | 3633 | 407 | 1869 |
|
Chip 1
|
A
|
0 | 0 | 99.79 | 99.46 | 0.52 | 252.4 | 0 | 82.8 | 0/0 | 0 | 3607 | 402 | 1750 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.55 | 0.26 | 234.8 | 0 | 78.5 | 0/0 | 0 | 3633 | 368 | 1293 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.53 | 0.22 | 190.2 | 0 | 61.9 | 0/0 | 0 | 3567 | 422 | 2061 |
|
Chip 4
|
A
|
19 | 0 | 99.81 | 99.50 | 0.32 | 154.4 | 30 | 51.9 | 0/0 | 0 | 3647 | 392 | 1659 |
|
Chip 5
|
A
|
0 | 0 | 99.80 | 99.58 | 0.38 | 214.6 | 0 | 70.4 | 0/0 | 0 | 3630 | 406 | 1842 |
|
Chip 6
|
A
|
0 | 0 | 99.81 | 99.56 | 0.21 | 160.0 | 1 | 52.6 | 0/0 | 0 | 3614 | 392 | 1642 |
|
Chip 7
|
A
|
0 | 0 | 99.80 | 99.49 | 0.26 | 167.3 | 1 | 55.5 | 0/0 | 0 | 3639 | 394 | 1690 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.48 | 0.31 | 166.8 | 0 | 55.3 | 0/0 | 0 | 3612 | 375 | 1419 |
|
Chip 9
|
A
|
1 | 0 | 99.80 | 99.60 | 0.24 | 164.2 | 1 | 54.2 | 0/0 | 0 | 3745 | 343 | 919 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.51 | 0.31 | 189.6 | 0 | 63.1 | 0/0 | 0 | 3572 | 408 | 1881 |
|
Chip 11
|
A
|
4 | 0 | 99.80 | 99.58 | 0.3 | 143.8 | 11 | 48.3 | 0/0 | 0 | 3642 | 374 | 1360 |
|
Chip 12
|
A
|
4 | 0 | 99.82 | 99.55 | 0.26 | 143.1 | 4 | 47.6 | 0/0 | 0 | 3654 | 340 | 936 |
|
Chip 13
|
A
|
1 | 0 | 99.79 | 99.52 | 0.32 | 220.6 | 2 | 73.7 | 0/0 | 0 | 3647 | 373 | 1370 |
|
Chip 14
|
B
|
30 | 0 | 99.75 | 99.48 | 1.75 | 254.5 | 34 | 84.1 | 0/0 | 0 | 3496 | 421 | 2030 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.56 | 0.35 | 242.4 | 0 | 79.3 | 0/0 | 0 | 3637 | 386 | 1572 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-04 | |
| TestTime | Test Time | 14:41 | |
| TestDuration | Duration | 0:37:25 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 1234 | |
| nWarnings | # Warnings | 59 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 51 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 20 | |
| message_tokenchain_count | Token Chain Length | 158 | |
| message_readback_count | Readback start marker | 39 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
