Test Date: 2016-11-04 14:41
Analysis date: 2016-11-04 15:52
Analysis date: 2016-11-04 15:52
M1111 XRayHRQualification
Summary
| Module | Module | M1111 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 8/3/5 | |
| PixelDefects | Total Pixel Defects | 1633 | |
| BumpBondingDefects | Bump Bonding Defects | 1633 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.54 | % |
| Noise | Mean Noise | 391 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
C
|
135 | 0 | 99.82 | 99.65 | 0.2 | 182.0 | 177 | 60.8 | 0/0 | 0 | 3643 | 385 | 1587 |
|
Chip 1
|
A
|
9 | 0 | 99.82 | 99.58 | 0.23 | 201.8 | 9 | 68.4 | 0/0 | 0 | 3710 | 357 | 1101 |
|
Chip 2
|
B
|
136 | 0 | 99.81 | 99.48 | 0.32 | 213.2 | 141 | 70.0 | 0/0 | 0 | 3685 | 371 | 1375 |
|
Chip 3
|
A
|
6 | 0 | 99.83 | 99.57 | 0.17 | 175.9 | 7 | 58.6 | 0/0 | 0 | 3688 | 376 | 1425 |
|
Chip 4
|
A
|
7 | 0 | 99.81 | 99.66 | 0.25 | 180.4 | 12 | 60.2 | 0/0 | 0 | 3685 | 382 | 1525 |
|
Chip 5
|
A
|
10 | 0 | 99.80 | 99.50 | 0.4 | 279.7 | 12 | 92.8 | 0/0 | 0 | 3551 | 430 | 2191 |
|
Chip 6
|
A
|
0 | 0 | 99.81 | 99.55 | 0.27 | 246.6 | 0 | 82.1 | 0/0 | 0 | 3561 | 421 | 2072 |
|
Chip 7
|
A
|
3 | 0 | 99.82 | 99.52 | 0.24 | 247.6 | 4 | 82.3 | 0/0 | 0 | 3646 | 401 | 1757 |
|
Chip 8
|
A
|
8 | 0 | 99.80 | 99.52 | 0.36 | 264.2 | 12 | 88.1 | 0/0 | 0 | 3616 | 410 | 1899 |
|
Chip 9
|
C
|
181 | 0 | 99.78 | 99.47 | 0.39 | 234.6 | 188 | 78.5 | 0/0 | 0 | 3533 | 426 | 2157 |
|
Chip 10
|
A
|
7 | 0 | 99.78 | 99.49 | 0.36 | 267.5 | 9 | 87.1 | 0/0 | 0 | 3365 | 412 | 1944 |
|
Chip 11
|
C
|
317 | 0 | 99.79 | 99.52 | 0.31 | 174.5 | 321 | 59.0 | 0/0 | 0 | 3652 | 387 | 1574 |
|
Chip 12
|
B
|
66 | 0 | 99.80 | 99.63 | 0.22 | 150.8 | 77 | 50.2 | 0/0 | 0 | 3700 | 350 | 1007 |
|
Chip 13
|
C
|
290 | 0 | 99.80 | 99.50 | 0.35 | 217.0 | 314 | 72.4 | 0/0 | 0 | 3615 | 388 | 1595 |
|
Chip 14
|
B
|
105 | 0 | 99.81 | 99.54 | 0.26 | 183.2 | 115 | 61.1 | 0/0 | 0 | 3620 | 396 | 1706 |
|
Chip 15
|
C
|
353 | 0 | 99.83 | 99.51 | 0.23 | 182.1 | 369 | 60.6 | 0/0 | 0 | 3747 | 357 | 1131 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-04 | |
| TestTime | Test Time | 14:41 | |
| TestDuration | Duration | 0:37:25 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
