Test Date: 2016-11-04 14:01
Analysis date: 2016-11-04 14:46
Analysis date: 2016-11-04 14:46
M1110 XRayHRQualification
Summary
| Module | Module | M1110 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.53 | % |
| Noise | Mean Noise | 383 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.55 | 0.36 | 279.4 | 0 | 91.2 | 0/0 | 0 | 3601 | 407 | 1840 |
|
Chip 1
|
A
|
0 | 0 | 99.80 | 99.50 | 0.36 | 228.0 | 0 | 74.8 | 0/0 | 0 | 3573 | 385 | 1577 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.53 | 0.35 | 229.6 | 0 | 75.1 | 0/0 | 0 | 3621 | 381 | 1457 |
|
Chip 3
|
A
|
1 | 0 | 99.81 | 99.57 | 0.19 | 170.8 | 1 | 56.8 | 0/0 | 0 | 3642 | 369 | 1302 |
|
Chip 4
|
A
|
0 | 0 | 99.78 | 99.56 | 0.25 | 134.2 | 0 | 44.5 | 0/0 | 0 | 3720 | 340 | 868 |
|
Chip 5
|
A
|
0 | 0 | 99.81 | 99.53 | 0.23 | 165.7 | 0 | 55.1 | 0/0 | 0 | 3654 | 368 | 1282 |
|
Chip 6
|
A
|
0 | 0 | 99.80 | 99.47 | 0.34 | 174.4 | 0 | 57.1 | 0/0 | 0 | 3599 | 389 | 1627 |
|
Chip 7
|
A
|
0 | 0 | 99.81 | 99.56 | 0.26 | 152.1 | 0 | 50.1 | 0/0 | 0 | 3724 | 343 | 905 |
|
Chip 8
|
A
|
0 | 0 | 99.82 | 99.34 | 0.17 | 144.9 | 0 | 47.3 | 0/0 | 0 | 3626 | 395 | 1728 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.47 | 0.3 | 146.4 | 0 | 48.4 | 0/0 | 0 | 3646 | 394 | 1675 |
|
Chip 10
|
A
|
0 | 0 | 99.79 | 99.49 | 0.27 | 169.2 | 0 | 55.9 | 0/0 | 0 | 3624 | 392 | 1677 |
|
Chip 11
|
A
|
0 | 0 | 99.80 | 99.61 | 0.2 | 131.8 | 0 | 43.9 | 0/0 | 0 | 3663 | 384 | 1579 |
|
Chip 12
|
A
|
0 | 0 | 99.80 | 99.64 | 0.33 | 141.5 | 0 | 47.4 | 0/0 | 0 | 3563 | 416 | 2016 |
|
Chip 13
|
A
|
0 | 0 | 99.80 | 99.55 | 0.28 | 202.3 | 0 | 66.8 | 0/0 | 0 | 3635 | 397 | 1776 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 99.57 | 0.29 | 206.3 | 0 | 67.2 | 0/0 | 0 | 3640 | 379 | 1456 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.56 | 0.36 | 250.5 | 0 | 81.2 | 0/0 | 0 | 3599 | 395 | 1710 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-04 | |
| TestTime | Test Time | 14:01 | |
| TestDuration | Duration | 0:37:4 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
