Test Date: 2016-11-04 10:50
Analysis date: 2016-11-07 11:37
Analysis date: 2016-11-07 11:37
M1108 XRayHRQualification
| Comment | Comment | comment.txt: Bad DC on C9 |
Summary
| Module | Module | M1108 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | C | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 11 | |
| BumpBondingDefects | Bump Bonding Defects | 10 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.55 | % |
| Noise | Mean Noise | 385 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.83 | 99.60 | 0.26 | 264.5 | 0 | 84.3 | 0/0 | 0 | 3664 | 385 | 1545 |
|
Chip 1
|
A
|
0 | 0 | 99.80 | 99.49 | 0.4 | 248.3 | 0 | 81.7 | 0/0 | 0 | 3622 | 398 | 1731 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.56 | 0.35 | 255.0 | 0 | 82.5 | 0/0 | 0 | 3532 | 422 | 2091 |
|
Chip 3
|
A
|
0 | 0 | 99.79 | 99.53 | 0.39 | 167.6 | 0 | 55.6 | 0/0 | 0 | 3638 | 381 | 1474 |
|
Chip 4
|
A
|
7 | 0 | 99.82 | 99.68 | 0.17 | 136.7 | 7 | 45.8 | 0/0 | 0 | 3656 | 357 | 1126 |
|
Chip 5
|
A
|
0 | 0 | 99.79 | 99.51 | 0.3 | 170.7 | 0 | 56.7 | 0/0 | 0 | 3657 | 368 | 1305 |
|
Chip 6
|
A
|
0 | 0 | 99.80 | 99.44 | 0.46 | 154.9 | 0 | 51.6 | 0/0 | 0 | 3695 | 366 | 1281 |
|
Chip 7
|
A
|
0 | 0 | 99.80 | 99.66 | 0.22 | 158.6 | 0 | 52.4 | 0/0 | 0 | 3663 | 364 | 1220 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.45 | 0.28 | 160.0 | 0 | 52.5 | 0/0 | 0 | 3434 | 382 | 1493 |
|
Chip 9
|
A
|
0 | 0 | 99.78 | 99.51 | 0.27 | 148.0 | 0 | 49.2 | 0/0 | 0 | 3717 | 351 | 1066 |
|
Chip 10
|
A
|
1 | 0 | 99.82 | 99.56 | 0.26 | 169.8 | 0 | 55.8 | 0/0 | 0 | 3697 | 365 | 1234 |
|
Chip 11
|
A
|
0 | 0 | 99.79 | 99.55 | 0.26 | 155.2 | 0 | 52.5 | 0/0 | 0 | 3520 | 431 | 2220 |
|
Chip 12
|
A
|
1 | 0 | 99.81 | 99.56 | 0.24 | 167.5 | 1 | 56.1 | 0/0 | 0 | 3629 | 396 | 1768 |
|
Chip 13
|
A
|
2 | 0 | 99.81 | 99.54 | 0.3 | 228.5 | 2 | 76.0 | 0/0 | 0 | 3611 | 395 | 1716 |
|
Chip 14
|
A
|
0 | 0 | 99.80 | 99.55 | 0.42 | 247.1 | 0 | 81.7 | 0/0 | 0 | 3366 | 406 | 1846 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.56 | 0.32 | 252.0 | 0 | 82.8 | 0/0 | 0 | 3633 | 394 | 1713 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-04 | |
| TestTime | Test Time | 10:50 | |
| TestDuration | Duration | 0:38:41 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 304 | |
| nWarnings | # Warnings | 54 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 18 | |
| message_readback_count | Readback start marker | 36 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
