Test Date: 2016-11-03 17:06
Analysis date: 2016-11-03 18:18
Analysis date: 2016-11-03 18:18
M1107 XRayHRQualification
Summary
| Module | Module | M1107 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 157 | |
| BumpBondingDefects | Bump Bonding Defects | 157 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 150/300 | 99.81/99.39 | % |
| Noise | Mean Noise | 366 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.81 | 99.55 | 0.41 | 256.5 | 1 | 83.8 | 0/0 | 0 | 3670 | 367 | 1274 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.56 | 0.36 | 246.4 | 0 | 81.0 | 0/0 | 0 | 3675 | 364 | 1248 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.55 | 0.41 | 223.9 | 0 | 73.4 | 0/0 | 0 | 3647 | 369 | 1290 |
|
Chip 3
|
A
|
0 | 0 | 99.79 | 99.51 | 0.28 | 147.1 | 0 | 49.3 | 0/0 | 0 | 3717 | 331 | 771 |
|
Chip 4
|
A
|
0 | 0 | 99.83 | 99.47 | 0.25 | 137.9 | 0 | 46.1 | 0/0 | 0 | 3736 | 342 | 906 |
|
Chip 5
|
A
|
0 | 0 | 99.79 | 99.49 | 0.31 | 196.8 | 0 | 65.4 | 0/0 | 0 | 3653 | 375 | 1407 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 99.49 | 0.33 | 170.0 | 0 | 56.8 | 0/0 | 0 | 3681 | 373 | 1354 |
|
Chip 7
|
A
|
0 | 0 | 99.81 | 99.44 | 0.25 | 154.8 | 0 | 51.1 | 0/0 | 0 | 3465 | 358 | 1114 |
|
Chip 8
|
C
|
156 | 0 | 99.84 | 97.53 | 42.83 | 158.6 | 158 | 52.4 | 0/0 | 2 | 3680 | 361 | 1195 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.45 | 0.25 | 154.3 | 0 | 51.1 | 0/0 | 0 | 3682 | 364 | 1219 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.52 | 0.27 | 175.7 | 0 | 58.7 | 0/0 | 0 | 3703 | 345 | 941 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.53 | 0.23 | 144.3 | 0 | 48.4 | 0/0 | 0 | 3737 | 339 | 890 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.50 | 0.3 | 167.8 | 0 | 55.7 | 0/0 | 0 | 3628 | 389 | 1621 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 99.56 | 0.51 | 271.8 | 0 | 89.6 | 0/0 | 0 | 3540 | 411 | 1927 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 99.56 | 0.37 | 264.2 | 0 | 86.4 | 0/0 | 0 | 3594 | 391 | 1688 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.57 | 0.43 | 262.4 | 0 | 86.4 | 0/0 | 0 | 3634 | 383 | 1499 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-03 | |
| TestTime | Test Time | 17:06 | |
| TestDuration | Duration | 0:43:59 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 23 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 1 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 1 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
