Test Date: 2016-11-14 14:49
Analysis date: 2016-11-14 15:34
Analysis date: 2016-11-14 15:34
M1106 XRayHRQualification
Summary
| Module | Module | M1106 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 3 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 150/300 | 99.81/99.55 | % |
| Noise | Mean Noise | 396 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.61 | 0.25 | 233.7 | 0 | 78.2 | 0/0 | 0 | 3643 | 373 | 1417 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.61 | 0.26 | 212.8 | 0 | 72.6 | 0/0 | 0 | 3688 | 336 | 828 |
|
Chip 2
|
A
|
0 | 0 | 99.81 | 99.50 | 0.31 | 240.0 | 0 | 80.2 | 0/0 | 0 | 3569 | 407 | 1854 |
|
Chip 3
|
A
|
0 | 0 | 99.79 | 99.50 | 0.32 | 196.6 | 0 | 65.6 | 0/0 | 0 | 3492 | 413 | 1981 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.59 | 0.22 | 178.7 | 0 | 60.4 | 0/0 | 0 | 3678 | 361 | 1185 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.57 | 0.33 | 262.1 | 0 | 87.7 | 0/0 | 0 | 3496 | 419 | 2070 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 99.54 | 0.4 | 277.7 | 0 | 92.4 | 0/0 | 0 | 3520 | 419 | 2008 |
|
Chip 7
|
A
|
0 | 0 | 99.81 | 99.52 | 0.39 | 290.8 | 0 | 96.4 | 0/0 | 0 | 3576 | 407 | 1833 |
|
Chip 8
|
A
|
0 | 0 | 99.79 | 99.47 | 0.32 | 288.4 | 0 | 96.3 | 0/0 | 0 | 3661 | 376 | 1413 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.56 | 0.34 | 289.0 | 0 | 94.6 | 0/0 | 0 | 3534 | 421 | 2109 |
|
Chip 10
|
A
|
0 | 0 | 99.84 | 99.55 | 0.34 | 304.8 | 0 | 102.5 | 0/0 | 0 | 3606 | 400 | 1784 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.55 | 0.25 | 200.4 | 0 | 67.4 | 0/0 | 0 | 3599 | 389 | 1604 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 99.55 | 0.19 | 178.3 | 0 | 59.2 | 0/0 | 0 | 3651 | 368 | 1324 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 99.57 | 0.36 | 290.6 | 0 | 93.6 | 0/0 | 0 | 3413 | 453 | 2454 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.54 | 0.44 | 261.3 | 0 | 86.2 | 0/0 | 0 | 3528 | 417 | 2025 |
|
Chip 15
|
C
|
3 | 0 | 99.80 | 99.54 | 0.76 | 243.6 | 3 | 83.1 | 0/0 | 2 | 3607 | 372 | 1353 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-14 | |
| TestTime | Test Time | 14:49 | |
| TestDuration | Duration | 0:38:7 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
v1.1.1-1-g54fa876 on branch master
