Test Date: 2016-11-08 16:03
Analysis date: 2016-11-08 16:53
Analysis date: 2016-11-08 16:53
M1105 XRayHRQualification
Summary
| Module | Module | M1105 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 5 | |
| BumpBondingDefects | Bump Bonding Defects | 5 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.55 | % |
| Noise | Mean Noise | 393 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.78 | 99.51 | 0.4 | 212.9 | 0 | 71.9 | 0/0 | 0 | 3621 | 387 | 1611 |
|
Chip 1
|
A
|
0 | 0 | 99.81 | 99.58 | 0.24 | 205.4 | 0 | 68.8 | 0/0 | 0 | 3646 | 377 | 1456 |
|
Chip 2
|
A
|
0 | 0 | 99.81 | 99.59 | 0.24 | 219.1 | 0 | 73.0 | 0/0 | 0 | 3576 | 399 | 1756 |
|
Chip 3
|
A
|
0 | 0 | 99.80 | 99.55 | 0.24 | 166.1 | 0 | 55.5 | 0/0 | 0 | 3655 | 370 | 1314 |
|
Chip 4
|
A
|
0 | 0 | 99.80 | 99.55 | 0.19 | 192.5 | 0 | 64.2 | 0/0 | 0 | 3588 | 411 | 1944 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.57 | 0.35 | 248.3 | 0 | 82.2 | 0/0 | 0 | 3593 | 389 | 1635 |
|
Chip 6
|
A
|
0 | 0 | 99.81 | 99.59 | 0.35 | 247.6 | 0 | 81.5 | 0/0 | 0 | 3598 | 391 | 1603 |
|
Chip 7
|
A
|
0 | 0 | 99.81 | 99.52 | 0.37 | 330.4 | 0 | 108.7 | 0/0 | 0 | 3477 | 446 | 2312 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.59 | 0.44 | 301.7 | 0 | 100.8 | 0/0 | 0 | 3636 | 380 | 1485 |
|
Chip 9
|
A
|
0 | 0 | 99.83 | 99.59 | 0.31 | 249.0 | 0 | 82.6 | 0/0 | 0 | 3665 | 383 | 1517 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.58 | 0.36 | 267.9 | 0 | 89.4 | 0/0 | 0 | 3555 | 400 | 1771 |
|
Chip 11
|
A
|
0 | 0 | 99.80 | 99.47 | 0.29 | 196.3 | 0 | 65.2 | 0/0 | 0 | 3574 | 409 | 1886 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 99.55 | 0.22 | 172.5 | 0 | 57.5 | 0/0 | 0 | 3599 | 378 | 1469 |
|
Chip 13
|
A
|
0 | 0 | 99.80 | 99.48 | 0.46 | 254.5 | 0 | 83.7 | 0/0 | 0 | 3538 | 428 | 2180 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.55 | 0.27 | 218.1 | 1 | 74.0 | 0/0 | 0 | 3658 | 364 | 1237 |
|
Chip 15
|
A
|
5 | 0 | 99.80 | 99.61 | 0.23 | 231.7 | 7 | 77.8 | 0/0 | 0 | 3634 | 382 | 1542 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-08 | |
| TestTime | Test Time | 16:03 | |
| TestDuration | Duration | 0:38:38 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
v1.1.1-1-g54fa876 on branch master
