Test Date: 2016-11-03 16:24
Analysis date: 2016-11-03 17:14
Analysis date: 2016-11-03 17:14
M1102 XRayHRQualification
Summary
| Module | Module | M1102 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 14/0/2 | |
| PixelDefects | Total Pixel Defects | 158 | |
| BumpBondingDefects | Bump Bonding Defects | 158 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 2 | |
| Efficiency | Efficiency 150/300 | 99.82/99.56 | % |
| Noise | Mean Noise | 391 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
C
|
0 | 0 | 99.82 | 99.52 | 0.36 | 237.2 | 0 | 80.1 | 0/0 | 1 | 3568 | 395 | 1724 |
|
Chip 1
|
C
|
158 | 0 | 99.78 | 99.59 | 3.49 | 222.3 | 160 | 74.6 | 0/0 | 2 | 3465 | 412 | 1947 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.57 | 0.25 | 248.0 | 0 | 83.5 | 0/0 | 0 | 3617 | 387 | 1555 |
|
Chip 3
|
A
|
0 | 0 | 99.85 | 99.61 | 0.23 | 169.6 | 0 | 56.7 | 0/0 | 0 | 3742 | 331 | 862 |
|
Chip 4
|
A
|
0 | 0 | 99.79 | 99.56 | 0.26 | 190.5 | 0 | 63.9 | 0/0 | 0 | 3614 | 389 | 1627 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.60 | 0.36 | 292.6 | 0 | 96.1 | 0/0 | 0 | 3492 | 426 | 2065 |
|
Chip 6
|
A
|
0 | 0 | 99.81 | 99.59 | 0.27 | 266.6 | 0 | 90.6 | 0/0 | 0 | 3345 | 405 | 1823 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.52 | 0.3 | 251.0 | 0 | 82.6 | 0/0 | 0 | 3680 | 364 | 1223 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.58 | 0.44 | 290.7 | 0 | 96.6 | 0/0 | 0 | 3711 | 404 | 1845 |
|
Chip 9
|
A
|
0 | 0 | 99.83 | 99.55 | 0.43 | 278.3 | 0 | 92.8 | 0/0 | 0 | 3632 | 402 | 1812 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.54 | 0.34 | 284.8 | 0 | 93.1 | 0/0 | 0 | 3600 | 399 | 1732 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.58 | 0.17 | 165.8 | 0 | 55.2 | 0/0 | 0 | 3700 | 350 | 1063 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.58 | 0.22 | 181.3 | 0 | 60.7 | 0/0 | 0 | 3581 | 400 | 1782 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.53 | 0.32 | 260.6 | 0 | 86.9 | 0/0 | 0 | 3523 | 418 | 2052 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 99.53 | 0.31 | 220.3 | 0 | 73.7 | 0/0 | 0 | 3590 | 388 | 1604 |
|
Chip 15
|
A
|
0 | 0 | 99.80 | 99.54 | 0.26 | 228.3 | 0 | 75.5 | 0/0 | 0 | 3617 | 389 | 1612 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-03 | |
| TestTime | Test Time | 16:24 | |
| TestDuration | Duration | 0:37:58 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
