Test Date: 2016-11-03 15:45
Analysis date: 2016-11-03 16:28
Analysis date: 2016-11-03 16:28
M1100 XRayHRQualification
Summary
| Module | Module | M1100 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.80/99.54 | % |
| Noise | Mean Noise | 404 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.80 | 99.59 | 0.59 | 227.6 | 0 | 77.4 | 0/0 | 0 | 3570 | 409 | 1905 |
|
Chip 1
|
A
|
0 | 0 | 99.78 | 99.52 | 0.39 | 214.2 | 0 | 71.7 | 0/0 | 0 | 3560 | 370 | 1302 |
|
Chip 2
|
A
|
0 | 0 | 99.80 | 99.58 | 0.43 | 267.8 | 0 | 89.7 | 0/0 | 0 | 3512 | 413 | 2002 |
|
Chip 3
|
A
|
0 | 0 | 99.77 | 99.50 | 0.38 | 190.4 | 0 | 63.9 | 0/0 | 0 | 3626 | 376 | 1432 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.58 | 0.29 | 167.1 | 0 | 56.9 | 0/0 | 0 | 3724 | 337 | 816 |
|
Chip 5
|
A
|
1 | 0 | 99.81 | 99.57 | 0.54 | 265.1 | 1 | 88.1 | 0/0 | 0 | 3546 | 424 | 2108 |
|
Chip 6
|
A
|
0 | 0 | 99.79 | 99.52 | 0.35 | 264.0 | 0 | 88.5 | 0/0 | 0 | 3493 | 428 | 2173 |
|
Chip 7
|
A
|
0 | 0 | 99.78 | 99.46 | 0.44 | 256.1 | 0 | 86.3 | 0/0 | 0 | 3538 | 428 | 2141 |
|
Chip 8
|
A
|
0 | 0 | 99.80 | 99.48 | 0.5 | 298.3 | 0 | 99.4 | 0/0 | 0 | 3550 | 427 | 2118 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.49 | 0.58 | 257.2 | 0 | 85.9 | 0/0 | 0 | 3628 | 396 | 1728 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.52 | 0.39 | 293.6 | 0 | 97.0 | 0/0 | 0 | 3498 | 426 | 2086 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.60 | 0.3 | 165.3 | 0 | 55.2 | 0/0 | 0 | 3656 | 365 | 1238 |
|
Chip 12
|
A
|
0 | 0 | 99.83 | 99.54 | 0.26 | 162.5 | 0 | 54.6 | 0/0 | 0 | 3588 | 399 | 1767 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 99.54 | 0.34 | 255.3 | 0 | 85.5 | 0/0 | 0 | 3473 | 436 | 2247 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 99.55 | 0.51 | 231.3 | 0 | 77.5 | 0/0 | 0 | 3516 | 425 | 2125 |
|
Chip 15
|
A
|
0 | 0 | 99.80 | 99.56 | 0.34 | 233.9 | 0 | 77.4 | 0/0 | 0 | 3536 | 397 | 1746 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-03 | |
| TestTime | Test Time | 15:45 | |
| TestDuration | Duration | 0:37:8 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 1076 | |
| nWarnings | # Warnings | 778 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 777 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 261 | |
| message_readback_count | Readback start marker | 516 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
