Test Date: 2016-11-04 10:50
Analysis date: 2016-11-04 11:49
Analysis date: 2016-11-04 11:49
M1099 XRayHRQualification
Summary
| Module | Module | M1099 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 174 | |
| BumpBondingDefects | Bump Bonding Defects | 159 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 14 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 150/300 | 99.81/99.56 | % |
| Noise | Mean Noise | 378 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.80 | 99.43 | 0.35 | 203.3 | 1 | 68.0 | 0/0 | 0 | 3659 | 369 | 1296 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.62 | 0.21 | 214.2 | 0 | 72.2 | 0/0 | 0 | 3668 | 361 | 1185 |
|
Chip 2
|
A
|
0 | 0 | 99.81 | 99.58 | 0.34 | 244.2 | 0 | 82.5 | 0/0 | 0 | 3588 | 403 | 1822 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.57 | 0.23 | 178.0 | 0 | 59.5 | 0/0 | 0 | 3669 | 352 | 1081 |
|
Chip 4
|
A
|
0 | 0 | 99.81 | 99.55 | 0.19 | 168.9 | 0 | 58.0 | 0/0 | 0 | 3695 | 347 | 967 |
|
Chip 5
|
A
|
0 | 0 | 99.81 | 99.53 | 0.44 | 287.5 | 0 | 96.1 | 0/0 | 0 | 3575 | 420 | 2014 |
|
Chip 6
|
A
|
0 | 0 | 99.81 | 99.56 | 0.37 | 271.4 | 0 | 91.4 | 0/0 | 0 | 3590 | 403 | 1782 |
|
Chip 7
|
A
|
1 | 0 | 99.80 | 99.51 | 0.37 | 292.2 | 1 | 98.8 | 0/0 | 0 | 3646 | 389 | 1597 |
|
Chip 8
|
A
|
1 | 0 | 99.83 | 99.58 | 0.35 | 292.9 | 0 | 98.9 | 0/0 | 0 | 3712 | 374 | 1418 |
|
Chip 9
|
A
|
0 | 0 | 99.80 | 99.54 | 0.36 | 285.3 | 0 | 96.1 | 0/0 | 0 | 3672 | 369 | 1351 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.57 | 0.36 | 288.3 | 0 | 95.9 | 0/0 | 0 | 3666 | 374 | 1403 |
|
Chip 11
|
A
|
0 | 0 | 99.79 | 99.52 | 0.34 | 198.6 | 0 | 67.2 | 0/0 | 0 | 3573 | 388 | 1579 |
|
Chip 12
|
A
|
13 | 0 | 99.82 | 99.59 | 0.23 | 189.7 | 0 | 63.1 | 0/0 | 0 | 3636 | 379 | 1416 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.65 | 0.29 | 238.4 | 0 | 79.9 | 0/0 | 0 | 3652 | 355 | 1118 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.60 | 0.29 | 238.4 | 0 | 78.7 | 0/0 | 0 | 3605 | 388 | 1611 |
|
Chip 15
|
C
|
158 | 0 | 99.83 | 99.54 | 0.21 | 232.4 | 159 | 77.7 | 0/0 | 2 | 3660 | 374 | 1371 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-04 | |
| TestTime | Test Time | 10:50 | |
| TestDuration | Duration | 0:38:41 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
