Test Date: 2016-11-03 15:03
Analysis date: 2016-11-03 15:51
Analysis date: 2016-11-03 15:51
M1098 XRayHRQualification
Summary
| Module | Module | M1098 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 3 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.54 | % |
| Noise | Mean Noise | 386 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.83 | 99.58 | 0.33 | 249.2 | 1 | 81.6 | 0/0 | 0 | 3676 | 385 | 1602 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.57 | 0.38 | 238.9 | 0 | 79.0 | 0/0 | 0 | 3416 | 386 | 1564 |
|
Chip 2
|
A
|
2 | 0 | 99.82 | 99.54 | 0.39 | 258.2 | 2 | 85.5 | 0/0 | 0 | 3588 | 408 | 1861 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.61 | 0.26 | 172.4 | 0 | 56.4 | 0/0 | 0 | 3640 | 377 | 1421 |
|
Chip 4
|
A
|
0 | 0 | 99.81 | 99.60 | 0.22 | 158.7 | 0 | 52.9 | 0/0 | 0 | 3606 | 396 | 1721 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.49 | 0.36 | 188.4 | 0 | 62.7 | 0/0 | 0 | 3618 | 387 | 1594 |
|
Chip 6
|
A
|
0 | 0 | 99.80 | 99.79 | 0.26 | 152.0 | 0 | 50.0 | 0/0 | 0 | 3663 | 362 | 1168 |
|
Chip 7
|
A
|
0 | 0 | 99.84 | 99.31 | 0.2 | 164.4 | 0 | 54.1 | 0/0 | 0 | 3667 | 377 | 1426 |
|
Chip 8
|
A
|
0 | 0 | 99.82 | 99.53 | 0.29 | 148.9 | 0 | 49.2 | 0/0 | 0 | 3684 | 367 | 1288 |
|
Chip 9
|
A
|
0 | 0 | 99.79 | 99.40 | 0.25 | 166.8 | 0 | 55.5 | 0/0 | 0 | 3688 | 382 | 1556 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.49 | 0.23 | 165.5 | 0 | 54.7 | 0/0 | 0 | 3665 | 377 | 1435 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.54 | 0.18 | 154.7 | 0 | 51.6 | 0/0 | 0 | 3625 | 397 | 1706 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.54 | 0.37 | 147.8 | 0 | 49.3 | 0/0 | 0 | 3682 | 380 | 1509 |
|
Chip 13
|
A
|
0 | 0 | 99.80 | 99.60 | 0.32 | 228.1 | 0 | 74.9 | 0/0 | 0 | 3658 | 381 | 1463 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.56 | 0.46 | 249.1 | 0 | 82.2 | 0/0 | 0 | 3347 | 406 | 1833 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.56 | 0.33 | 239.5 | 0 | 79.2 | 0/0 | 0 | 3584 | 406 | 1874 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-03 | |
| TestTime | Test Time | 15:03 | |
| TestDuration | Duration | 0:37:48 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
