Test Date: 2016-11-01 09:05
Analysis date: 2016-11-01 09:49
Analysis date: 2016-11-01 09:49
M1096 XRayHRQualification
Summary
| Module | Module | M1096 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 0 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.80/99.54 | % |
| Noise | Mean Noise | 359 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.80 | 99.50 | 0.33 | 237.1 | 0 | 76.6 | 0/0 | 0 | 3562 | 360 | 1241 |
|
Chip 1
|
A
|
0 | 0 | 99.81 | 99.58 | 0.33 | 205.2 | 0 | 66.3 | 0/0 | 0 | 3706 | 355 | 1114 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.56 | 0.39 | 233.5 | 0 | 74.7 | 0/0 | 0 | 3721 | 367 | 1309 |
|
Chip 3
|
A
|
0 | 0 | 99.80 | 99.53 | 0.31 | 152.7 | 0 | 50.5 | 0/0 | 0 | 3498 | 330 | 748 |
|
Chip 4
|
A
|
0 | 0 | 99.78 | 99.51 | 0.28 | 143.8 | 0 | 47.6 | 0/0 | 0 | 3722 | 347 | 1068 |
|
Chip 5
|
A
|
0 | 0 | 99.79 | 99.53 | 0.29 | 183.6 | 0 | 60.2 | 0/0 | 0 | 3672 | 349 | 1078 |
|
Chip 6
|
A
|
0 | 0 | 99.78 | 99.55 | 0.37 | 173.3 | 0 | 56.7 | 0/0 | 0 | 3712 | 375 | 1461 |
|
Chip 7
|
A
|
0 | 0 | 99.81 | 99.55 | 0.32 | 171.7 | 0 | 55.9 | 0/0 | 0 | 3633 | 375 | 1406 |
|
Chip 8
|
A
|
0 | 0 | 99.80 | 99.69 | 0.24 | 140.8 | 0 | 45.7 | 0/0 | 0 | 3774 | 330 | 723 |
|
Chip 9
|
A
|
0 | 0 | 99.77 | 99.46 | 0.41 | 150.6 | 0 | 49.4 | 0/0 | 0 | 3693 | 355 | 1100 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.51 | 0.25 | 174.5 | 0 | 57.1 | 0/0 | 0 | 3730 | 352 | 1048 |
|
Chip 11
|
A
|
0 | 0 | 99.79 | 99.62 | 0.2 | 134.9 | 0 | 44.1 | 0/0 | 0 | 3759 | 332 | 829 |
|
Chip 12
|
A
|
0 | 0 | 99.80 | 99.52 | 0.25 | 134.6 | 0 | 44.5 | 0/0 | 0 | 3751 | 342 | 945 |
|
Chip 13
|
A
|
0 | 0 | 99.80 | 99.52 | 0.36 | 184.9 | 0 | 60.4 | 0/0 | 0 | 3743 | 346 | 972 |
|
Chip 14
|
A
|
0 | 0 | 99.80 | 99.53 | 0.3 | 231.0 | 0 | 75.1 | 0/0 | 0 | 3656 | 392 | 1660 |
|
Chip 15
|
A
|
0 | 0 | 99.81 | 99.52 | 0.35 | 264.2 | 0 | 85.1 | 0/0 | 0 | 3538 | 431 | 2209 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-01 | |
| TestTime | Test Time | 09:05 | |
| TestDuration | Duration | 0:37:11 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
