Test Date: 2016-10-29 13:53
Analysis date: 2016-10-31 11:54
Analysis date: 2016-10-31 11:54
M1094 XRayHRQualification
Summary
| Module | Module | M1094 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 2 | |
| BumpBondingDefects | Bump Bonding Defects | 2 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.50 | % |
| Noise | Mean Noise | 317 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.52 | 0.39 | 64.2 | 198.2 | 0 | 0/0 | 0 | 3838 | 318 | 667 |
|
Chip 1
|
A
|
1 | 0 | 99.82 | 99.57 | 0.31 | 60.9 | 187.9 | 1 | 0/0 | 0 | 3838 | 310 | 504 |
|
Chip 2
|
A
|
0 | 0 | 99.78 | 99.53 | 0.51 | 73.2 | 224.1 | 0 | 0/0 | 0 | 3791 | 346 | 1017 |
|
Chip 3
|
A
|
0 | 0 | 99.80 | 99.55 | 0.29 | 44.0 | 132.5 | 0 | 0/0 | 0 | 3884 | 309 | 535 |
|
Chip 4
|
A
|
0 | 0 | 99.79 | 99.49 | 0.23 | 43.1 | 131.2 | 0 | 0/0 | 0 | 3881 | 320 | 632 |
|
Chip 5
|
A
|
1 | 0 | 99.81 | 99.54 | 0.31 | 49.6 | 150.5 | 1 | 0/0 | 0 | 3854 | 333 | 778 |
|
Chip 6
|
A
|
0 | 0 | 99.83 | 99.35 | 0.19 | 42.0 | 128.5 | 0 | 0/0 | 0 | 3904 | 298 | 391 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.13 | 0.19 | 39.3 | 120.4 | 0 | 0/0 | 0 | 3931 | 290 | 294 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.66 | 0.29 | 50.6 | 154.2 | 0 | 0/0 | 0 | 3774 | 316 | 621 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.43 | 0.23 | 52.3 | 159.1 | 0 | 0/0 | 0 | 3850 | 310 | 488 |
|
Chip 10
|
A
|
0 | 0 | 99.78 | 99.48 | 0.33 | 54.1 | 165.3 | 0 | 0/0 | 0 | 3832 | 318 | 573 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.69 | 0.17 | 39.8 | 120.6 | 0 | 0/0 | 0 | 3917 | 313 | 576 |
|
Chip 12
|
A
|
0 | 0 | 99.78 | 99.50 | 0.28 | 48.3 | 146.8 | 0 | 0/0 | 0 | 3816 | 324 | 736 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.50 | 0.28 | 54.9 | 169.4 | 0 | 0/0 | 0 | 3837 | 294 | 349 |
|
Chip 14
|
A
|
0 | 0 | 99.79 | 99.53 | 0.37 | 72.2 | 219.5 | 1 | 0/0 | 0 | 3783 | 329 | 724 |
|
Chip 15
|
A
|
0 | 0 | 99.80 | 99.54 | 0.29 | 76.2 | 235.8 | 0 | 0/0 | 0 | 3788 | 344 | 982 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-29 | |
| TestTime | Test Time | 13:53 | |
| TestDuration | Duration | 0:57:2 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 200684 | |
| nWarnings | # Warnings | 390 | |
| channel_0_count | Channel 0 | 138 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 642 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 208 | |
| message_notokenpass_count | has NoTokenPass | 184 | |
| message_tokenchain_count | Token Chain Length | 4 | |
| message_readback_count | Readback start marker | 384 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
