Test Date: 2016-11-04 10:08
Analysis date: 2016-11-04 11:47
Analysis date: 2016-11-04 11:47
M1092 XRayHRQualification
Summary
| Module | Module | M1092 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 41 | |
| BumpBondingDefects | Bump Bonding Defects | 39 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.63 | % |
| Noise | Mean Noise | 386 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.80 | 99.54 | 0.39 | 272.8 | 0 | 89.0 | 0/0 | 0 | 3480 | 435 | 2287 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.57 | 0.38 | 256.8 | 0 | 83.2 | 0/0 | 0 | 3585 | 422 | 2089 |
|
Chip 2
|
A
|
0 | 0 | 99.81 | 99.64 | 0.25 | 228.7 | 0 | 75.3 | 0/0 | 0 | 3528 | 415 | 1973 |
|
Chip 3
|
A
|
0 | 0 | 99.79 | 99.61 | 0.34 | 159.7 | 0 | 52.8 | 0/0 | 0 | 3639 | 377 | 1440 |
|
Chip 4
|
A
|
1 | 0 | 99.82 | 99.73 | 0.18 | 154.7 | 1 | 51.2 | 0/0 | 0 | 3677 | 375 | 1443 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.52 | 0.26 | 207.4 | 0 | 67.9 | 0/0 | 0 | 3696 | 348 | 999 |
|
Chip 6
|
A
|
0 | 0 | 99.80 | 99.36 | 0.24 | 166.3 | 0 | 54.8 | 0/0 | 0 | 3634 | 408 | 1930 |
|
Chip 7
|
A
|
2 | 0 | 99.81 | 99.75 | 0.21 | 150.9 | 0 | 49.4 | 0/0 | 0 | 3676 | 378 | 1438 |
|
Chip 8
|
A
|
0 | 0 | 99.79 | 99.90 | 0.35 | 167.8 | 0 | 55.3 | 0/0 | 0 | 3619 | 393 | 1688 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.95 | 0.2 | 171.8 | 0 | 56.5 | 0/0 | 0 | 3692 | 356 | 1153 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 99.54 | 0.21 | 179.2 | 0 | 59.5 | 0/0 | 0 | 3686 | 351 | 1028 |
|
Chip 11
|
A
|
2 | 0 | 99.80 | 99.64 | 0.2 | 142.2 | 2 | 47.5 | 0/0 | 0 | 3670 | 336 | 836 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.49 | 0.28 | 152.4 | 1 | 50.8 | 0/0 | 0 | 3612 | 374 | 1396 |
|
Chip 13
|
A
|
0 | 0 | 99.80 | 99.60 | 0.28 | 234.7 | 0 | 76.7 | 0/0 | 0 | 3523 | 416 | 2015 |
|
Chip 14
|
A
|
18 | 0 | 99.83 | 99.64 | 0.31 | 231.5 | 18 | 74.1 | 0/0 | 0 | 3642 | 395 | 1687 |
|
Chip 15
|
A
|
18 | 0 | 99.81 | 99.56 | 0.4 | 273.8 | 19 | 89.2 | 0/0 | 0 | 3624 | 390 | 1682 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-04 | |
| TestTime | Test Time | 10:08 | |
| TestDuration | Duration | 0:38:3 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 864 | |
| nWarnings | # Warnings | 149 | |
| channel_0_count | Channel 0 | 6 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 150 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 52 | |
| message_tokenchain_count | Token Chain Length | 7 | |
| message_readback_count | Readback start marker | 97 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
