Test Date: 2016-11-04 10:08
Analysis date: 2016-11-04 10:58
Analysis date: 2016-11-04 10:58
M1091 XRayHRQualification
Summary
| Module | Module | M1091 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 0 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.56 | % |
| Noise | Mean Noise | 370 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 99.50 | 0.21 | 217.4 | 0 | 72.9 | 0/0 | 0 | 3660 | 336 | 872 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.57 | 0.23 | 234.6 | 0 | 75.7 | 0/0 | 0 | 3606 | 387 | 1534 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.58 | 0.35 | 241.1 | 0 | 80.8 | 0/0 | 0 | 3658 | 347 | 1038 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.54 | 0.23 | 202.6 | 0 | 67.1 | 0/0 | 0 | 3331 | 394 | 1692 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.63 | 0.19 | 168.8 | 0 | 57.4 | 0/0 | 0 | 3688 | 324 | 689 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.52 | 0.32 | 276.2 | 0 | 90.8 | 0/0 | 0 | 3556 | 402 | 1771 |
|
Chip 6
|
A
|
0 | 0 | 99.83 | 99.58 | 0.37 | 269.1 | 0 | 88.7 | 0/0 | 0 | 3615 | 392 | 1648 |
|
Chip 7
|
A
|
0 | 0 | 99.83 | 99.58 | 0.29 | 264.1 | 0 | 88.5 | 0/0 | 0 | 3711 | 369 | 1351 |
|
Chip 8
|
A
|
0 | 0 | 99.80 | 99.50 | 0.38 | 302.9 | 0 | 101.4 | 0/0 | 0 | 3621 | 386 | 1552 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.56 | 0.34 | 288.4 | 0 | 96.5 | 0/0 | 0 | 3387 | 395 | 1675 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.59 | 0.29 | 272.7 | 0 | 91.7 | 0/0 | 0 | 3645 | 367 | 1319 |
|
Chip 11
|
A
|
0 | 0 | 99.84 | 99.61 | 0.14 | 183.0 | 0 | 60.5 | 0/0 | 0 | 3648 | 377 | 1449 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.44 | 0.23 | 157.9 | 0 | 53.0 | 0/0 | 0 | 3707 | 352 | 1088 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.59 | 0.26 | 226.0 | 0 | 75.0 | 0/0 | 0 | 3649 | 367 | 1311 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 99.60 | 0.31 | 236.2 | 0 | 77.7 | 0/0 | 0 | 3655 | 362 | 1215 |
|
Chip 15
|
A
|
0 | 0 | 99.84 | 99.59 | 0.26 | 218.1 | 0 | 72.5 | 0/0 | 0 | 3647 | 362 | 1229 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-04 | |
| TestTime | Test Time | 10:08 | |
| TestDuration | Duration | 0:38:3 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
