Test Date: 2016-11-01 12:00
Analysis date: 2016-11-01 13:24
Analysis date: 2016-11-01 13:24
M1089 XRayHRQualification
Summary
| Module | Module | M1089 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 6 | |
| BumpBondingDefects | Bump Bonding Defects | 4 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.60 | % |
| Noise | Mean Noise | 333 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
3 | 0 | 99.82 | 99.56 | 0.25 | 67.0 | 203.1 | 1 | 0/0 | 0 | 3749 | 325 | 766 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.60 | 0.23 | 70.3 | 217.4 | 0 | 0/0 | 0 | 3756 | 351 | 1116 |
|
Chip 2
|
A
|
0 | 0 | 99.78 | 99.65 | 0.37 | 61.6 | 184.5 | 0 | 0/0 | 0 | 3832 | 332 | 832 |
|
Chip 3
|
A
|
1 | 0 | 99.81 | 99.65 | 0.16 | 47.6 | 143.3 | 1 | 0/0 | 0 | 3816 | 298 | 413 |
|
Chip 4
|
A
|
0 | 0 | 99.83 | 99.65 | 0.13 | 51.2 | 152.2 | 0 | 0/0 | 0 | 3846 | 303 | 404 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.65 | 0.28 | 73.7 | 224.3 | 0 | 0/0 | 0 | 3570 | 319 | 685 |
|
Chip 6
|
A
|
1 | 0 | 99.82 | 99.51 | 0.24 | 73.5 | 222.9 | 1 | 0/0 | 0 | 3790 | 340 | 979 |
|
Chip 7
|
A
|
1 | 0 | 99.82 | 99.59 | 0.26 | 75.0 | 223.8 | 1 | 0/0 | 0 | 3813 | 323 | 770 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.55 | 0.42 | 91.3 | 276.1 | 0 | 0/0 | 0 | 3753 | 357 | 1221 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.57 | 0.3 | 79.7 | 242.0 | 0 | 0/0 | 0 | 3823 | 324 | 796 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.53 | 0.32 | 86.4 | 264.7 | 0 | 0/0 | 0 | 3734 | 363 | 1317 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.61 | 0.19 | 56.2 | 169.1 | 0 | 0/0 | 0 | 3772 | 342 | 945 |
|
Chip 12
|
A
|
0 | 0 | 99.83 | 99.68 | 0.13 | 48.7 | 147.8 | 0 | 0/0 | 0 | 3833 | 320 | 642 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.61 | 0.23 | 69.1 | 211.6 | 0 | 0/0 | 0 | 3743 | 335 | 885 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 99.55 | 0.21 | 78.8 | 239.2 | 0 | 0/0 | 0 | 3529 | 356 | 1214 |
|
Chip 15
|
A
|
0 | 0 | 99.81 | 99.58 | 0.31 | 75.6 | 230.4 | 0 | 0/0 | 0 | 3778 | 341 | 994 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-01 | |
| TestTime | Test Time | 12:00 | |
| TestDuration | Duration | 0:57:42 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
