Test Date: 2016-10-31 18:09
Analysis date: 2016-11-01 14:03
Analysis date: 2016-11-01 14:03
M1087 XRayHRQualification
Summary
| Module | Module | M1087 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 9 | |
| BumpBondingDefects | Bump Bonding Defects | 9 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.55 | % |
| Noise | Mean Noise | 335 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.55 | 0.33 | 53.8 | 163.0 | 0 | 0/0 | 0 | 3844 | 303 | 432 |
|
Chip 1
|
A
|
0 | 0 | 99.81 | 99.52 | 0.41 | 62.5 | 189.4 | 0 | 0/0 | 0 | 3782 | 341 | 916 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.53 | 0.34 | 64.3 | 192.9 | 0 | 0/0 | 0 | 3536 | 327 | 746 |
|
Chip 3
|
A
|
0 | 0 | 99.80 | 99.50 | 0.26 | 48.9 | 146.7 | 0 | 0/0 | 0 | 3848 | 322 | 683 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.54 | 0.27 | 51.2 | 154.9 | 0 | 0/0 | 0 | 3798 | 318 | 641 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.52 | 0.31 | 76.8 | 231.9 | 0 | 0/0 | 0 | 3708 | 351 | 1112 |
|
Chip 6
|
A
|
0 | 0 | 99.81 | 99.70 | 0.19 | 59.1 | 177.3 | 0 | 0/0 | 0 | 3826 | 311 | 555 |
|
Chip 7
|
A
|
1 | 0 | 99.79 | 99.60 | 0.31 | 80.2 | 240.3 | 1 | 0/0 | 0 | 3780 | 339 | 923 |
|
Chip 8
|
A
|
0 | 0 | 99.79 | 99.44 | 0.48 | 109.7 | 331.5 | 1 | 0/0 | 0 | 3747 | 379 | 1530 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.52 | 0.31 | 97.6 | 301.0 | 0 | 0/0 | 0 | 3725 | 373 | 1461 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.56 | 0.34 | 82.2 | 252.5 | 0 | 0/0 | 0 | 3517 | 342 | 999 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.57 | 0.27 | 59.3 | 178.5 | 0 | 0/0 | 0 | 3781 | 318 | 679 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 99.59 | 0.22 | 53.3 | 159.8 | 0 | 0/0 | 0 | 3612 | 312 | 561 |
|
Chip 13
|
A
|
0 | 0 | 99.79 | 99.55 | 0.35 | 74.7 | 226.0 | 0 | 0/0 | 0 | 3723 | 351 | 1089 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.57 | 0.29 | 70.4 | 212.5 | 0 | 0/0 | 0 | 3791 | 345 | 1048 |
|
Chip 15
|
A
|
8 | 0 | 99.84 | 99.57 | 0.3 | 65.3 | 200.9 | 15 | 0/0 | 0 | 3812 | 333 | 845 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-31 | |
| TestTime | Test Time | 18:09 | |
| TestDuration | Duration | 0:56:55 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
