Test Date: 2016-10-31 17:08
Analysis date: 2016-10-31 18:14
Analysis date: 2016-10-31 18:14
M1086 XRayHRQualification
Summary
| Module | Module | M1086 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 0 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.56 | % |
| Noise | Mean Noise | 309 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 99.57 | 0.4 | 57.1 | 180.8 | 0 | 0/0 | 0 | 3811 | 315 | 579 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.47 | 0.27 | 48.5 | 150.6 | 0 | 0/0 | 0 | 3719 | 299 | 368 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.55 | 0.32 | 57.0 | 176.7 | 0 | 0/0 | 0 | 3859 | 310 | 516 |
|
Chip 3
|
A
|
0 | 0 | 99.84 | 99.60 | 0.2 | 40.2 | 122.8 | 0 | 0/0 | 0 | 3875 | 296 | 431 |
|
Chip 4
|
A
|
0 | 0 | 99.83 | 99.60 | 0.2 | 36.0 | 109.9 | 0 | 0/0 | 0 | 3881 | 281 | 246 |
|
Chip 5
|
A
|
0 | 0 | 99.80 | 99.58 | 0.28 | 48.4 | 148.4 | 0 | 0/0 | 0 | 3587 | 328 | 783 |
|
Chip 6
|
A
|
0 | 0 | 99.83 | 99.43 | 0.22 | 41.0 | 126.8 | 0 | 0/0 | 0 | 3866 | 304 | 453 |
|
Chip 7
|
A
|
0 | 0 | 99.83 | 99.45 | 0.21 | 44.4 | 137.4 | 0 | 0/0 | 0 | 3854 | 321 | 727 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.49 | 0.2 | 39.9 | 122.7 | 0 | 0/0 | 0 | 3874 | 292 | 323 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.55 | 0.22 | 43.4 | 134.1 | 0 | 0/0 | 0 | 3797 | 302 | 425 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.75 | 0.22 | 44.2 | 136.6 | 0 | 0/0 | 0 | 3843 | 308 | 471 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.70 | 0.22 | 35.9 | 110.6 | 0 | 0/0 | 0 | 3914 | 289 | 364 |
|
Chip 12
|
A
|
0 | 0 | 99.85 | 99.56 | 0.22 | 39.3 | 119.7 | 0 | 0/0 | 0 | 3908 | 293 | 411 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 99.50 | 0.27 | 63.6 | 194.9 | 0 | 0/0 | 0 | 3634 | 332 | 789 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 99.53 | 0.29 | 53.0 | 164.4 | 0 | 0/0 | 0 | 3805 | 331 | 838 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.56 | 0.36 | 70.4 | 221.7 | 0 | 0/0 | 0 | 3754 | 344 | 985 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-31 | |
| TestTime | Test Time | 17:08 | |
| TestDuration | Duration | 0:57:3 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
