Test Date: 2016-10-31 16:06
Analysis date: 2016-10-31 17:17
Analysis date: 2016-10-31 17:17
M1083 XRayHRQualification
Summary
| Module | Module | M1083 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.83/99.58 | % |
| Noise | Mean Noise | 320 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.83 | 99.68 | 0.22 | 65.9 | 202.9 | 0 | 0/0 | 0 | 3734 | 319 | 684 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.63 | 0.21 | 60.2 | 183.2 | 0 | 0/0 | 0 | 3848 | 294 | 361 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.59 | 0.31 | 65.6 | 195.5 | 0 | 0/0 | 0 | 3825 | 318 | 626 |
|
Chip 3
|
A
|
0 | 0 | 99.83 | 99.56 | 0.23 | 51.5 | 154.1 | 0 | 0/0 | 0 | 3839 | 314 | 606 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.60 | 0.16 | 53.2 | 159.9 | 0 | 0/0 | 0 | 3749 | 311 | 514 |
|
Chip 5
|
A
|
0 | 0 | 99.84 | 99.55 | 0.29 | 73.8 | 222.1 | 0 | 0/0 | 0 | 3548 | 311 | 600 |
|
Chip 6
|
A
|
0 | 0 | 99.83 | 99.56 | 0.28 | 70.1 | 211.2 | 0 | 0/0 | 0 | 3846 | 304 | 506 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.67 | 0.27 | 67.0 | 199.7 | 0 | 0/0 | 0 | 3816 | 299 | 427 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.57 | 0.33 | 93.1 | 286.3 | 0 | 0/0 | 0 | 3761 | 377 | 1499 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.58 | 0.26 | 87.9 | 268.1 | 0 | 0/0 | 0 | 3659 | 351 | 1134 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 99.57 | 0.19 | 63.5 | 197.6 | 0 | 0/0 | 0 | 3839 | 287 | 314 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.44 | 0.19 | 52.2 | 156.6 | 0 | 0/0 | 0 | 3822 | 300 | 481 |
|
Chip 12
|
A
|
0 | 0 | 99.83 | 99.59 | 0.21 | 57.8 | 176.0 | 0 | 0/0 | 0 | 3542 | 317 | 708 |
|
Chip 13
|
A
|
1 | 0 | 99.82 | 99.58 | 0.24 | 83.4 | 252.3 | 1 | 0/0 | 0 | 3758 | 347 | 1098 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 99.61 | 0.3 | 65.1 | 197.8 | 0 | 0/0 | 0 | 3818 | 319 | 660 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.52 | 0.24 | 71.7 | 223.0 | 0 | 0/0 | 0 | 3749 | 349 | 1115 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-31 | |
| TestTime | Test Time | 16:06 | |
| TestDuration | Duration | 0:58:0 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
