Test Date: 2016-11-03 14:20
Analysis date: 2016-11-03 15:11
Analysis date: 2016-11-03 15:11
M1082 XRayHRQualification
Summary
| Module | Module | M1082 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.56 | % |
| Noise | Mean Noise | 373 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.79 | 99.48 | 0.35 | 248.1 | 0 | 81.8 | 0/0 | 0 | 3438 | 446 | 2372 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.58 | 0.22 | 214.9 | 0 | 71.1 | 0/0 | 0 | 3620 | 376 | 1403 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.55 | 0.35 | 218.6 | 0 | 71.3 | 0/0 | 0 | 3631 | 372 | 1379 |
|
Chip 3
|
A
|
0 | 0 | 99.79 | 99.58 | 0.22 | 152.4 | 0 | 51.1 | 0/0 | 0 | 3727 | 327 | 669 |
|
Chip 4
|
A
|
0 | 0 | 99.83 | 99.56 | 0.16 | 163.5 | 0 | 54.4 | 0/0 | 0 | 3698 | 345 | 949 |
|
Chip 5
|
A
|
0 | 0 | 99.80 | 99.51 | 0.37 | 267.0 | 0 | 87.8 | 0/0 | 0 | 3541 | 419 | 2028 |
|
Chip 6
|
A
|
0 | 0 | 99.83 | 99.59 | 0.23 | 210.7 | 0 | 68.3 | 0/0 | 0 | 3687 | 358 | 1157 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.59 | 0.36 | 230.9 | 0 | 75.8 | 0/0 | 0 | 3639 | 392 | 1669 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.62 | 0.29 | 227.4 | 0 | 75.1 | 0/0 | 0 | 3713 | 355 | 1088 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.53 | 0.31 | 224.4 | 0 | 71.9 | 0/0 | 0 | 3684 | 370 | 1356 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.53 | 0.32 | 246.6 | 0 | 80.0 | 0/0 | 0 | 3672 | 375 | 1404 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.54 | 0.29 | 178.8 | 0 | 59.1 | 0/0 | 0 | 3643 | 376 | 1403 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 99.65 | 0.18 | 162.6 | 0 | 53.7 | 0/0 | 0 | 3637 | 366 | 1296 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.57 | 0.23 | 220.7 | 0 | 72.4 | 0/0 | 0 | 3621 | 379 | 1443 |
|
Chip 14
|
A
|
0 | 0 | 99.80 | 99.54 | 0.28 | 184.7 | 0 | 60.1 | 0/0 | 0 | 3660 | 353 | 1110 |
|
Chip 15
|
A
|
1 | 0 | 99.83 | 99.53 | 0.26 | 189.5 | 1 | 62.8 | 0/0 | 0 | 3643 | 358 | 1160 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-03 | |
| TestTime | Test Time | 14:20 | |
| TestDuration | Duration | 0:36:53 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 31 | |
| nWarnings | # Warnings | 6 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 3 | |
| channel_3_count | Channel 3 | 3 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_readback_count | Readback start marker | 4 |
