Test Date: 2016-10-31 15:05
Analysis date: 2016-10-31 16:11
Analysis date: 2016-10-31 16:11
M1081 XRayHRQualification
Summary
| Module | Module | M1081 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 7 | |
| BumpBondingDefects | Bump Bonding Defects | 6 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.57 | % |
| Noise | Mean Noise | 306 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
4 | 0 | 99.82 | 99.53 | 0.35 | 78.3 | 243.3 | 4 | 0/0 | 0 | 3760 | 335 | 905 |
|
Chip 1
|
A
|
1 | 0 | 99.81 | 99.55 | 0.38 | 67.7 | 211.4 | 0 | 0/0 | 0 | 3813 | 316 | 620 |
|
Chip 2
|
A
|
0 | 0 | 99.84 | 99.56 | 0.24 | 57.9 | 179.3 | 0 | 0/0 | 0 | 3831 | 304 | 479 |
|
Chip 3
|
A
|
2 | 0 | 99.84 | 99.60 | 0.21 | 47.0 | 143.3 | 2 | 0/0 | 0 | 3883 | 286 | 297 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.59 | 0.18 | 36.1 | 109.7 | 0 | 0/0 | 0 | 3945 | 260 | 160 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.54 | 0.17 | 46.4 | 141.7 | 0 | 0/0 | 0 | 3894 | 296 | 350 |
|
Chip 6
|
A
|
0 | 0 | 99.83 | 99.51 | 0.23 | 51.6 | 158.8 | 0 | 0/0 | 0 | 3777 | 342 | 976 |
|
Chip 7
|
A
|
0 | 0 | 99.81 | 99.71 | 0.18 | 46.5 | 143.1 | 0 | 0/0 | 0 | 3826 | 318 | 624 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.48 | 0.16 | 41.0 | 125.4 | 0 | 0/0 | 0 | 3858 | 301 | 449 |
|
Chip 9
|
A
|
0 | 0 | 99.83 | 99.49 | 0.17 | 38.3 | 117.8 | 0 | 0/0 | 0 | 3887 | 298 | 370 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 99.48 | 0.21 | 48.5 | 148.0 | 0 | 0/0 | 0 | 3857 | 311 | 537 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.78 | 0.16 | 33.0 | 100.1 | 0 | 0/0 | 0 | 3950 | 264 | 173 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 99.65 | 0.2 | 43.2 | 130.5 | 0 | 0/0 | 0 | 3878 | 310 | 587 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 99.53 | 0.41 | 63.9 | 197.8 | 0 | 0/0 | 0 | 3603 | 319 | 645 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.50 | 0.29 | 64.0 | 196.8 | 0 | 0/0 | 0 | 3821 | 320 | 677 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.62 | 0.2 | 64.5 | 201.5 | 0 | 0/0 | 0 | 3837 | 316 | 638 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-31 | |
| TestTime | Test Time | 15:05 | |
| TestDuration | Duration | 0:57:33 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
