Test Date: 2016-10-31 15:05
Analysis date: 2016-10-31 16:09
Analysis date: 2016-10-31 16:09
M1080 XRayHRQualification
Summary
| Module | Module | M1080 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 5 | |
| BumpBondingDefects | Bump Bonding Defects | 5 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.56 | % |
| Noise | Mean Noise | 322 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.78 | 99.57 | 0.29 | 64.0 | 194.4 | 1 | 0/0 | 0 | 3547 | 324 | 736 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.54 | 0.33 | 61.5 | 190.1 | 0 | 0/0 | 0 | 3821 | 321 | 700 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.57 | 0.3 | 61.0 | 186.2 | 0 | 0/0 | 0 | 3539 | 318 | 604 |
|
Chip 3
|
A
|
1 | 0 | 99.82 | 99.62 | 0.22 | 46.9 | 142.2 | 1 | 0/0 | 0 | 3821 | 304 | 450 |
|
Chip 4
|
A
|
1 | 0 | 99.84 | 99.60 | 0.19 | 50.2 | 150.9 | 1 | 0/0 | 0 | 3821 | 313 | 545 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.55 | 0.25 | 66.0 | 202.0 | 0 | 0/0 | 0 | 3793 | 336 | 878 |
|
Chip 6
|
A
|
0 | 0 | 99.83 | 99.51 | 0.44 | 72.4 | 220.9 | 0 | 0/0 | 0 | 3770 | 348 | 1073 |
|
Chip 7
|
A
|
0 | 0 | 99.83 | 99.55 | 0.43 | 84.9 | 257.1 | 0 | 0/0 | 0 | 3800 | 330 | 857 |
|
Chip 8
|
A
|
0 | 0 | 99.82 | 99.57 | 0.37 | 85.3 | 261.4 | 0 | 0/0 | 0 | 3814 | 332 | 871 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.58 | 0.3 | 75.1 | 229.3 | 0 | 0/0 | 0 | 3796 | 317 | 653 |
|
Chip 10
|
A
|
0 | 0 | 99.80 | 99.54 | 0.53 | 95.9 | 290.3 | 0 | 0/0 | 0 | 3759 | 361 | 1260 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.62 | 0.37 | 51.4 | 155.7 | 0 | 0/0 | 0 | 3820 | 294 | 372 |
|
Chip 12
|
A
|
0 | 0 | 99.80 | 99.51 | 0.21 | 55.2 | 170.5 | 0 | 0/0 | 0 | 3863 | 335 | 872 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.57 | 0.3 | 61.5 | 186.4 | 0 | 0/0 | 0 | 3814 | 306 | 477 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 99.58 | 0.19 | 59.5 | 182.2 | 0 | 0/0 | 0 | 3851 | 297 | 443 |
|
Chip 15
|
A
|
2 | 0 | 99.79 | 99.54 | 0.37 | 71.4 | 215.7 | 2 | 0/0 | 0 | 3705 | 323 | 707 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-31 | |
| TestTime | Test Time | 15:05 | |
| TestDuration | Duration | 0:57:33 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
