Test Date: 2016-10-31 14:00
Analysis date: 2016-10-31 15:11
Analysis date: 2016-10-31 15:11
M1079 XRayHRQualification
Summary
| Module | Module | M1079 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 2 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.54 | % |
| Noise | Mean Noise | 318 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.82 | 99.57 | 0.34 | 73.3 | 228.9 | 1 | 0/0 | 0 | 3771 | 362 | 1288 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.57 | 0.31 | 74.7 | 234.0 | 0 | 0/0 | 0 | 3547 | 349 | 1097 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.57 | 0.3 | 67.1 | 206.7 | 0 | 0/0 | 0 | 3757 | 353 | 1132 |
|
Chip 3
|
A
|
0 | 0 | 99.83 | 99.62 | 0.19 | 43.9 | 134.8 | 0 | 0/0 | 0 | 3858 | 295 | 350 |
|
Chip 4
|
A
|
0 | 0 | 99.80 | 99.62 | 0.19 | 43.3 | 131.1 | 0 | 0/0 | 0 | 3861 | 302 | 437 |
|
Chip 5
|
A
|
0 | 0 | 99.80 | 99.36 | 0.3 | 49.2 | 152.0 | 0 | 0/0 | 0 | 3828 | 320 | 670 |
|
Chip 6
|
A
|
0 | 0 | 99.84 | 99.50 | 0.18 | 41.1 | 126.3 | 0 | 0/0 | 0 | 3841 | 296 | 383 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.55 | 0.21 | 48.3 | 147.7 | 0 | 0/0 | 0 | 3845 | 330 | 787 |
|
Chip 8
|
A
|
0 | 0 | 99.82 | 99.69 | 0.29 | 42.1 | 128.7 | 0 | 0/0 | 0 | 3896 | 310 | 551 |
|
Chip 9
|
A
|
0 | 0 | 99.83 | 99.30 | 0.17 | 39.8 | 122.1 | 0 | 0/0 | 0 | 3894 | 278 | 211 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.46 | 0.24 | 48.5 | 148.2 | 0 | 0/0 | 0 | 3881 | 302 | 445 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.62 | 0.14 | 38.2 | 117.3 | 0 | 0/0 | 0 | 3902 | 281 | 289 |
|
Chip 12
|
A
|
1 | 0 | 99.81 | 99.55 | 0.24 | 42.8 | 129.3 | 0 | 0/0 | 0 | 3837 | 305 | 509 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.53 | 0.34 | 64.8 | 198.4 | 0 | 0/0 | 0 | 3800 | 336 | 901 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.60 | 0.29 | 71.7 | 221.0 | 0 | 0/0 | 0 | 3771 | 337 | 969 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.59 | 0.34 | 78.7 | 246.4 | 0 | 0/0 | 0 | 3822 | 341 | 968 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-31 | |
| TestTime | Test Time | 14:00 | |
| TestDuration | Duration | 1:2:5 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
