Test Date: 2016-10-31 14:00
Analysis date: 2016-10-31 15:09
Analysis date: 2016-10-31 15:09
M1078 XRayHRQualification
Summary
| Module | Module | M1078 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 2 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.58 | % |
| Noise | Mean Noise | 351 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 99.56 | 0.17 | 71.4 | 216.9 | 0 | 0/0 | 0 | 3761 | 322 | 727 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.62 | 0.23 | 67.7 | 202.8 | 0 | 0/0 | 0 | 3723 | 346 | 1047 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.57 | 0.35 | 78.7 | 239.4 | 0 | 0/0 | 0 | 3729 | 346 | 1067 |
|
Chip 3
|
A
|
0 | 0 | 99.83 | 99.64 | 0.22 | 57.4 | 171.0 | 0 | 0/0 | 0 | 3767 | 343 | 959 |
|
Chip 4
|
A
|
0 | 0 | 99.84 | 99.60 | 0.2 | 54.4 | 162.6 | 0 | 0/0 | 0 | 3788 | 319 | 654 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.58 | 0.41 | 86.7 | 259.0 | 0 | 0/0 | 0 | 3724 | 365 | 1304 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 99.58 | 0.31 | 88.8 | 264.0 | 0 | 0/0 | 0 | 3734 | 349 | 1086 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.58 | 0.35 | 105.3 | 309.8 | 0 | 0/0 | 0 | 3557 | 381 | 1561 |
|
Chip 8
|
A
|
1 | 0 | 99.82 | 99.55 | 0.42 | 102.5 | 303.4 | 0 | 0/0 | 0 | 3719 | 379 | 1479 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.56 | 0.42 | 93.7 | 285.1 | 0 | 0/0 | 0 | 3700 | 380 | 1549 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.52 | 0.34 | 82.4 | 244.3 | 0 | 0/0 | 0 | 3516 | 352 | 1114 |
|
Chip 11
|
A
|
1 | 0 | 99.82 | 99.63 | 0.25 | 57.6 | 171.1 | 1 | 0/0 | 0 | 3806 | 313 | 587 |
|
Chip 12
|
A
|
1 | 0 | 99.82 | 99.57 | 0.22 | 56.6 | 170.9 | 1 | 0/0 | 0 | 3725 | 339 | 920 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.51 | 0.28 | 80.9 | 245.3 | 0 | 0/0 | 0 | 3666 | 376 | 1448 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.64 | 0.38 | 78.2 | 235.6 | 0 | 0/0 | 0 | 3491 | 368 | 1337 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.62 | 0.27 | 73.3 | 217.3 | 0 | 0/0 | 0 | 3755 | 340 | 982 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-31 | |
| TestTime | Test Time | 14:00 | |
| TestDuration | Duration | 1:2:5 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
