Test Date: 2016-10-31 13:00
Analysis date: 2016-10-31 14:05
Analysis date: 2016-10-31 14:05
M1076 XRayHRQualification
Summary
| Module | Module | M1076 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 7 | |
| BumpBondingDefects | Bump Bonding Defects | 7 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.57 | % |
| Noise | Mean Noise | 315 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.53 | 0.29 | 85.8 | 267.9 | 0 | 0/0 | 0 | 3769 | 340 | 985 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.57 | 0.28 | 75.3 | 231.7 | 0 | 0/0 | 0 | 3785 | 323 | 744 |
|
Chip 2
|
A
|
0 | 0 | 99.81 | 99.54 | 0.37 | 79.6 | 245.7 | 0 | 0/0 | 0 | 3407 | 347 | 1079 |
|
Chip 3
|
A
|
0 | 0 | 99.83 | 99.61 | 0.25 | 50.3 | 153.8 | 0 | 0/0 | 0 | 3836 | 303 | 506 |
|
Chip 4
|
A
|
0 | 0 | 99.84 | 99.59 | 0.2 | 40.6 | 123.3 | 0 | 0/0 | 0 | 3841 | 291 | 335 |
|
Chip 5
|
A
|
1 | 0 | 99.83 | 99.59 | 0.23 | 56.8 | 175.9 | 1 | 0/0 | 0 | 3571 | 325 | 740 |
|
Chip 6
|
A
|
3 | 0 | 99.83 | 99.56 | 0.23 | 50.1 | 154.0 | 3 | 0/0 | 0 | 3632 | 334 | 829 |
|
Chip 7
|
A
|
1 | 0 | 99.80 | 99.52 | 0.32 | 59.0 | 180.2 | 2 | 0/0 | 0 | 3688 | 375 | 1408 |
|
Chip 8
|
A
|
1 | 0 | 99.82 | 99.66 | 0.23 | 41.0 | 126.0 | 1 | 0/0 | 0 | 3835 | 307 | 504 |
|
Chip 9
|
A
|
1 | 0 | 99.81 | 99.64 | 0.24 | 45.1 | 138.0 | 1 | 0/0 | 0 | 3837 | 323 | 656 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.43 | 0.23 | 50.6 | 154.7 | 0 | 0/0 | 0 | 3845 | 302 | 416 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.58 | 0.22 | 37.0 | 112.5 | 0 | 0/0 | 0 | 3732 | 267 | 198 |
|
Chip 12
|
A
|
0 | 0 | 99.84 | 99.64 | 0.23 | 42.8 | 130.8 | 0 | 0/0 | 0 | 3876 | 278 | 264 |
|
Chip 13
|
A
|
0 | 0 | 99.80 | 99.49 | 0.3 | 55.6 | 173.6 | 0 | 0/0 | 0 | 3821 | 283 | 234 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 99.59 | 0.24 | 55.8 | 175.9 | 0 | 0/0 | 0 | 3880 | 293 | 358 |
|
Chip 15
|
A
|
0 | 0 | 99.80 | 99.52 | 0.35 | 82.3 | 257.0 | 0 | 0/0 | 0 | 3751 | 346 | 1047 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-31 | |
| TestTime | Test Time | 13:00 | |
| TestDuration | Duration | 0:56:43 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 31 | |
| nWarnings | # Warnings | 2 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 1 | |
| message_readback_count | Readback start marker | 2 |
