Test Date: 2016-10-31 13:00
Analysis date: 2016-10-31 14:03
Analysis date: 2016-10-31 14:03
M1075 XRayHRQualification
Summary
| Module | Module | M1075 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 13 | |
| BumpBondingDefects | Bump Bonding Defects | 13 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.55 | % |
| Noise | Mean Noise | 345 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.80 | 99.37 | 0.27 | 56.3 | 170.8 | 1 | 0/0 | 0 | 3832 | 329 | 770 |
|
Chip 1
|
A
|
1 | 0 | 99.82 | 99.56 | 0.3 | 50.2 | 152.6 | 1 | 0/0 | 0 | 3822 | 333 | 801 |
|
Chip 2
|
A
|
1 | 0 | 99.81 | 99.61 | 0.23 | 70.3 | 213.8 | 1 | 0/0 | 0 | 3736 | 361 | 1229 |
|
Chip 3
|
A
|
0 | 0 | 99.82 | 99.56 | 0.21 | 43.3 | 129.8 | 0 | 0/0 | 0 | 3866 | 293 | 326 |
|
Chip 4
|
A
|
0 | 0 | 99.83 | 99.58 | 0.2 | 48.0 | 145.6 | 0 | 0/0 | 0 | 3830 | 320 | 639 |
|
Chip 5
|
A
|
1 | 0 | 99.82 | 99.54 | 0.4 | 80.0 | 241.7 | 1 | 0/0 | 0 | 3482 | 379 | 1482 |
|
Chip 6
|
A
|
3 | 0 | 99.83 | 99.58 | 0.34 | 80.0 | 246.7 | 3 | 0/0 | 0 | 3725 | 383 | 1555 |
|
Chip 7
|
A
|
2 | 0 | 99.79 | 99.48 | 0.47 | 80.8 | 245.5 | 3 | 0/0 | 0 | 3723 | 383 | 1554 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.56 | 0.39 | 75.2 | 229.7 | 0 | 0/0 | 0 | 3762 | 364 | 1274 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.57 | 0.32 | 81.4 | 245.2 | 1 | 0/0 | 0 | 3748 | 368 | 1355 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 99.57 | 0.31 | 83.9 | 257.9 | 0 | 0/0 | 0 | 3749 | 371 | 1419 |
|
Chip 11
|
A
|
0 | 0 | 99.84 | 99.61 | 0.2 | 46.5 | 141.8 | 0 | 0/0 | 0 | 3868 | 319 | 644 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 99.48 | 0.23 | 43.2 | 130.4 | 0 | 0/0 | 0 | 3896 | 298 | 381 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 99.58 | 0.31 | 66.1 | 201.6 | 0 | 0/0 | 0 | 3723 | 351 | 1136 |
|
Chip 14
|
A
|
2 | 0 | 99.81 | 99.57 | 0.31 | 57.8 | 176.1 | 2 | 0/0 | 0 | 3798 | 341 | 902 |
|
Chip 15
|
A
|
2 | 0 | 99.82 | 99.59 | 0.29 | 63.0 | 191.9 | 2 | 0/0 | 0 | 3564 | 334 | 852 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-31 | |
| TestTime | Test Time | 13:00 | |
| TestDuration | Duration | 0:56:43 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
