Test Date: 2016-10-31 11:57
Analysis date: 2016-10-31 13:05
Analysis date: 2016-10-31 13:05
M1074 XRayHRQualification
Summary
| Module | Module | M1074 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.60 | % |
| Noise | Mean Noise | 319 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.56 | 0.32 | 67.2 | 208.7 | 0 | 0/0 | 0 | 3819 | 334 | 876 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.59 | 0.27 | 64.5 | 202.1 | 0 | 0/0 | 0 | 3841 | 310 | 567 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.61 | 0.26 | 56.8 | 176.2 | 0 | 0/0 | 0 | 3843 | 312 | 549 |
|
Chip 3
|
A
|
0 | 0 | 99.78 | 99.45 | 0.26 | 44.6 | 135.4 | 0 | 0/0 | 0 | 3869 | 306 | 492 |
|
Chip 4
|
A
|
0 | 0 | 99.81 | 99.82 | 0.17 | 35.2 | 106.8 | 0 | 0/0 | 0 | 3916 | 268 | 178 |
|
Chip 5
|
A
|
0 | 0 | 99.80 | 99.55 | 0.19 | 42.8 | 131.2 | 1 | 0/0 | 0 | 3887 | 300 | 374 |
|
Chip 6
|
A
|
1 | 0 | 99.83 | 99.64 | 0.18 | 43.4 | 134.0 | 1 | 0/0 | 0 | 3866 | 317 | 631 |
|
Chip 7
|
A
|
0 | 0 | 99.79 | 99.80 | 0.25 | 43.0 | 131.2 | 0 | 0/0 | 0 | 3931 | 320 | 637 |
|
Chip 8
|
A
|
0 | 0 | 99.79 | 99.63 | 0.27 | 49.1 | 151.7 | 0 | 0/0 | 0 | 3631 | 334 | 873 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.43 | 0.27 | 52.2 | 159.9 | 0 | 0/0 | 0 | 3768 | 345 | 982 |
|
Chip 10
|
A
|
0 | 0 | 99.79 | 99.51 | 0.29 | 56.4 | 171.9 | 0 | 0/0 | 0 | 3846 | 330 | 790 |
|
Chip 11
|
A
|
0 | 0 | 99.83 | 99.63 | 0.12 | 40.1 | 122.0 | 0 | 0/0 | 0 | 3863 | 313 | 589 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.65 | 0.27 | 40.5 | 122.7 | 0 | 0/0 | 0 | 3836 | 303 | 473 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.59 | 0.26 | 55.0 | 170.1 | 0 | 0/0 | 0 | 3838 | 322 | 659 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.57 | 0.31 | 71.2 | 219.8 | 0 | 0/0 | 0 | 3741 | 360 | 1219 |
|
Chip 15
|
A
|
0 | 0 | 99.77 | 99.52 | 0.39 | 64.0 | 199.7 | 0 | 0/0 | 0 | 3775 | 335 | 815 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-31 | |
| TestTime | Test Time | 11:57 | |
| TestDuration | Duration | 0:57:5 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
