Test Date: 2016-10-28 16:13
Analysis date: 2016-10-28 18:32
Analysis date: 2016-10-28 18:32
M1071 XRayHRQualification
Summary
| Module | Module | M1071 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 22 | |
| BumpBondingDefects | Bump Bonding Defects | 18 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.42 | % |
| Noise | Mean Noise | 324 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
5 | 0 | 99.82 | 99.60 | 0.42 | 82.8 | 259.5 | 5 | 0/0 | 0 | 3754 | 347 | 1093 |
|
Chip 1
|
A
|
1 | 0 | 99.82 | 99.59 | 0.25 | 77.0 | 237.8 | 1 | 0/0 | 0 | 3629 | 337 | 920 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.64 | 0.27 | 70.3 | 219.8 | 0 | 0/0 | 0 | 3756 | 328 | 755 |
|
Chip 3
|
A
|
1 | 0 | 99.83 | 99.57 | 0.27 | 45.5 | 137.9 | 2 | 0/0 | 0 | 3830 | 310 | 507 |
|
Chip 4
|
A
|
1 | 0 | 99.83 | 99.56 | 0.21 | 42.8 | 130.6 | 1 | 0/0 | 0 | 3349 | 298 | 401 |
|
Chip 5
|
A
|
4 | 0 | 99.81 | 99.54 | 0.25 | 63.4 | 194.6 | 2 | 0/0 | 0 | 3474 | 344 | 1014 |
|
Chip 6
|
A
|
1 | 0 | 99.77 | 97.60 | 0.15 | 39.7 | 121.8 | 1 | 0/0 | 0 | 3832 | 292 | 310 |
|
Chip 7
|
A
|
0 | 0 | 99.78 | 98.43 | 0.2 | 43.4 | 133.5 | 0 | 0/0 | 0 | 3605 | 301 | 430 |
|
Chip 8
|
A
|
1 | 0 | 99.81 | 99.99 | 0.25 | 51.0 | 155.9 | 1 | 0/0 | 0 | 3808 | 347 | 1054 |
|
Chip 9
|
A
|
2 | 0 | 99.83 | 99.88 | 0.18 | 44.3 | 136.3 | 0 | 0/0 | 0 | 3837 | 307 | 499 |
|
Chip 10
|
A
|
2 | 0 | 99.81 | 99.57 | 0.25 | 61.9 | 188.5 | 2 | 0/0 | 0 | 3153 | 346 | 1038 |
|
Chip 11
|
A
|
4 | 0 | 99.83 | 99.62 | 0.25 | 47.2 | 142.5 | 4 | 0/0 | 0 | 3559 | 307 | 543 |
|
Chip 12
|
A
|
0 | 0 | 99.84 | 99.45 | 0.11 | 39.5 | 121.3 | 0 | 0/0 | 0 | 3837 | 290 | 341 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.51 | 0.25 | 61.4 | 191.7 | 1 | 0/0 | 0 | 3560 | 323 | 716 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.59 | 0.3 | 76.4 | 235.9 | 0 | 0/0 | 0 | 3712 | 351 | 1124 |
|
Chip 15
|
A
|
0 | 0 | 99.80 | 99.54 | 0.31 | 89.1 | 276.7 | 0 | 0/0 | 0 | 3724 | 362 | 1284 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-28 | |
| TestTime | Test Time | 16:13 | |
| TestDuration | Duration | 0:57:12 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
