Test Date: 2016-10-28 16:13
Analysis date: 2016-10-28 18:08
Analysis date: 2016-10-28 18:08
M1069 XRayHRQualification
Summary
| Module | Module | M1069 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 0 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.54 | % |
| Noise | Mean Noise | 337 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.82 | 99.47 | 0.26 | 57.1 | 171.7 | 0 | 0/0 | 0 | 3829 | 299 | 405 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.53 | 0.27 | 70.8 | 213.7 | 0 | 0/0 | 0 | 3766 | 338 | 951 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.58 | 0.31 | 72.3 | 216.8 | 0 | 0/0 | 0 | 3779 | 343 | 979 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.52 | 0.25 | 58.4 | 178.2 | 0 | 0/0 | 0 | 3575 | 337 | 884 |
|
Chip 4
|
A
|
0 | 0 | 99.81 | 99.58 | 0.28 | 61.4 | 185.4 | 0 | 0/0 | 0 | 3809 | 320 | 687 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.56 | 0.36 | 79.3 | 245.4 | 0 | 0/0 | 0 | 3761 | 338 | 925 |
|
Chip 6
|
A
|
0 | 0 | 99.81 | 99.56 | 0.26 | 79.9 | 237.3 | 1 | 0/0 | 0 | 3582 | 339 | 952 |
|
Chip 7
|
A
|
0 | 0 | 99.79 | 99.49 | 0.47 | 76.6 | 232.0 | 0 | 0/0 | 0 | 3797 | 339 | 971 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.56 | 0.49 | 84.2 | 253.1 | 0 | 0/0 | 0 | 3809 | 338 | 935 |
|
Chip 9
|
A
|
0 | 0 | 99.83 | 99.58 | 0.36 | 79.9 | 245.4 | 0 | 0/0 | 0 | 3761 | 336 | 907 |
|
Chip 10
|
A
|
0 | 0 | 99.80 | 99.51 | 0.35 | 88.7 | 276.4 | 0 | 0/0 | 0 | 3808 | 358 | 1258 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.52 | 0.24 | 58.8 | 176.0 | 0 | 0/0 | 0 | 3797 | 336 | 847 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 99.60 | 0.28 | 56.4 | 171.9 | 0 | 0/0 | 0 | 3771 | 358 | 1180 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 99.51 | 0.32 | 71.1 | 216.0 | 0 | 0/0 | 0 | 3476 | 351 | 1117 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 99.56 | 0.31 | 67.6 | 208.0 | 0 | 0/0 | 0 | 3791 | 333 | 841 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.55 | 0.39 | 66.4 | 204.7 | 0 | 0/0 | 0 | 3768 | 333 | 832 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-28 | |
| TestTime | Test Time | 16:13 | |
| TestDuration | Duration | 0:57:12 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 221 | |
| nWarnings | # Warnings | 42 | |
| channel_0_count | Channel 0 | 3 | |
| channel_1_count | Channel 1 | 9 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 14 | |
| message_readback_count | Readback start marker | 28 |
