Test Date: 2016-10-28 15:06
Analysis date: 2016-10-28 16:19
Analysis date: 2016-10-28 16:19
M1068 XRayHRQualification
Summary
| Module | Module | M1068 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.60 | % |
| Noise | Mean Noise | 335 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.82 | 99.53 | 0.35 | 73.0 | 231.0 | 0 | 0/0 | 0 | 3705 | 384 | 1542 |
|
Chip 1
|
A
|
1 | 0 | 99.81 | 99.54 | 0.26 | 69.7 | 216.4 | 1 | 0/0 | 0 | 3702 | 374 | 1404 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.57 | 0.24 | 70.0 | 218.1 | 0 | 0/0 | 0 | 3739 | 368 | 1351 |
|
Chip 3
|
A
|
0 | 0 | 99.83 | 99.66 | 0.24 | 43.4 | 132.6 | 0 | 0/0 | 0 | 3824 | 333 | 846 |
|
Chip 4
|
A
|
0 | 0 | 99.80 | 99.55 | 0.23 | 36.6 | 112.3 | 0 | 0/0 | 0 | 3876 | 318 | 664 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.82 | 0.16 | 43.5 | 134.8 | 0 | 0/0 | 0 | 3846 | 342 | 955 |
|
Chip 6
|
A
|
0 | 0 | 99.83 | 99.41 | 0.2 | 40.7 | 124.8 | 0 | 0/0 | 0 | 3882 | 316 | 600 |
|
Chip 7
|
A
|
0 | 0 | 99.84 | 99.99 | 0.21 | 36.2 | 112.3 | 0 | 0/0 | 0 | 3885 | 306 | 490 |
|
Chip 8
|
A
|
0 | 0 | 99.79 | 99.37 | 0.18 | 46.4 | 142.3 | 0 | 0/0 | 0 | 3888 | 334 | 891 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.60 | 0.23 | 45.9 | 139.5 | 0 | 0/0 | 0 | 3825 | 349 | 1059 |
|
Chip 10
|
A
|
0 | 0 | 99.79 | 99.76 | 0.26 | 42.4 | 128.8 | 0 | 0/0 | 0 | 3904 | 315 | 629 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.57 | 0.15 | 36.7 | 111.6 | 0 | 0/0 | 0 | 3905 | 289 | 332 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 99.50 | 0.33 | 35.8 | 107.7 | 0 | 0/0 | 0 | 3884 | 304 | 484 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.58 | 0.29 | 64.8 | 197.5 | 0 | 0/0 | 0 | 3783 | 349 | 1094 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 99.57 | 0.28 | 64.1 | 198.4 | 0 | 0/0 | 0 | 3528 | 352 | 1141 |
|
Chip 15
|
A
|
0 | 0 | 99.84 | 99.52 | 0.19 | 52.1 | 161.9 | 0 | 0/0 | 0 | 3850 | 323 | 694 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-28 | |
| TestTime | Test Time | 15:06 | |
| TestDuration | Duration | 0:56:40 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
