Test Date: 2016-10-27 18:13
Analysis date: 2016-10-27 19:16
Analysis date: 2016-10-27 19:16
M1066 XRayHRQualification
Summary
| Module | Module | M1066 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 3 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.63 | % |
| Noise | Mean Noise | 318 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.83 | 99.52 | 0.22 | 57.5 | 179.0 | 0 | 0/0 | 0 | 3842 | 337 | 866 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.43 | 0.31 | 48.2 | 148.8 | 0 | 0/0 | 0 | 3811 | 323 | 632 |
|
Chip 2
|
A
|
0 | 0 | 99.80 | 99.46 | 0.32 | 50.3 | 154.6 | 0 | 0/0 | 0 | 3596 | 341 | 914 |
|
Chip 3
|
A
|
2 | 0 | 99.83 | 99.61 | 0.23 | 38.2 | 115.8 | 2 | 0/0 | 0 | 3649 | 311 | 615 |
|
Chip 4
|
A
|
0 | 0 | 99.79 | 99.39 | 0.23 | 34.6 | 106.1 | 0 | 0/0 | 0 | 3880 | 309 | 585 |
|
Chip 5
|
A
|
1 | 0 | 99.83 | 99.69 | 0.16 | 39.1 | 119.6 | 1 | 0/0 | 0 | 3886 | 311 | 495 |
|
Chip 6
|
A
|
0 | 0 | 99.85 | 102.54 | 19.22 | 30.5 | 93.2 | 0 | 0/0 | 0 | 3894 | 284 | 299 |
|
Chip 7
|
A
|
0 | 0 | 99.78 | 97.78 | 0.15 | 31.0 | 95.3 | 0 | 0/0 | 0 | 3961 | 282 | 289 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.74 | 0.19 | 37.1 | 114.5 | 0 | 0/0 | 0 | 3895 | 319 | 664 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.81 | 0.2 | 39.7 | 121.9 | 0 | 0/0 | 0 | 3844 | 336 | 878 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 99.39 | 0.28 | 45.8 | 141.0 | 0 | 0/0 | 0 | 3881 | 343 | 922 |
|
Chip 11
|
A
|
0 | 0 | 99.85 | 99.57 | 0.14 | 30.7 | 94.3 | 0 | 0/0 | 0 | 3893 | 275 | 267 |
|
Chip 12
|
A
|
0 | 0 | 99.77 | 99.46 | 0.21 | 37.1 | 113.4 | 0 | 0/0 | 0 | 3925 | 296 | 454 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.61 | 0.28 | 59.5 | 182.6 | 0 | 0/0 | 0 | 3785 | 341 | 996 |
|
Chip 14
|
A
|
0 | 0 | 99.80 | 99.56 | 0.28 | 53.6 | 169.0 | 0 | 0/0 | 0 | 3846 | 336 | 880 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.51 | 0.29 | 63.5 | 198.1 | 0 | 0/0 | 0 | 3807 | 347 | 1013 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-27 | |
| TestTime | Test Time | 18:13 | |
| TestDuration | Duration | 0:56:31 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
