Test Date: 2016-10-27 18:13
Analysis date: 2016-10-27 19:15
Analysis date: 2016-10-27 19:15
M1065 XRayHRQualification
Summary
| Module | Module | M1065 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.57 | % |
| Noise | Mean Noise | 328 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.84 | 99.58 | 0.32 | 58.0 | 177.5 | 1 | 0/0 | 0 | 3813 | 328 | 770 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.59 | 0.3 | 59.2 | 179.8 | 0 | 0/0 | 0 | 3817 | 312 | 523 |
|
Chip 2
|
A
|
0 | 0 | 99.79 | 99.50 | 0.37 | 76.2 | 233.1 | 0 | 0/0 | 0 | 3499 | 339 | 916 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.59 | 0.28 | 45.6 | 140.3 | 0 | 0/0 | 0 | 3887 | 294 | 377 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.57 | 0.25 | 48.1 | 145.9 | 0 | 0/0 | 0 | 3838 | 319 | 627 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.55 | 0.3 | 71.6 | 220.2 | 0 | 0/0 | 0 | 3812 | 323 | 707 |
|
Chip 6
|
A
|
0 | 0 | 99.81 | 99.56 | 0.27 | 70.5 | 215.8 | 0 | 0/0 | 0 | 3816 | 322 | 707 |
|
Chip 7
|
A
|
0 | 0 | 99.79 | 99.51 | 0.46 | 85.8 | 259.1 | 0 | 0/0 | 0 | 3793 | 359 | 1179 |
|
Chip 8
|
A
|
0 | 0 | 99.79 | 99.52 | 0.39 | 85.2 | 258.7 | 0 | 0/0 | 0 | 3711 | 357 | 1190 |
|
Chip 9
|
A
|
0 | 0 | 99.84 | 99.59 | 0.23 | 65.4 | 202.9 | 0 | 0/0 | 0 | 3802 | 324 | 710 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 99.56 | 0.24 | 63.9 | 196.5 | 0 | 0/0 | 0 | 3814 | 326 | 760 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.60 | 0.27 | 57.3 | 172.6 | 0 | 0/0 | 0 | 3790 | 318 | 599 |
|
Chip 12
|
A
|
0 | 0 | 99.83 | 99.62 | 0.24 | 49.7 | 151.3 | 0 | 0/0 | 0 | 3847 | 316 | 574 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.60 | 0.24 | 73.5 | 224.9 | 0 | 0/0 | 0 | 3742 | 358 | 1187 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 99.59 | 0.32 | 65.0 | 198.8 | 0 | 0/0 | 0 | 3790 | 322 | 673 |
|
Chip 15
|
A
|
0 | 0 | 99.81 | 99.57 | 0.31 | 70.1 | 215.3 | 0 | 0/0 | 0 | 3824 | 324 | 743 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-27 | |
| TestTime | Test Time | 18:13 | |
| TestDuration | Duration | 0:56:31 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
