Test Date: 2016-10-27 12:31
Analysis date: 2016-10-27 13:57
Analysis date: 2016-10-27 13:57
M1064 XRayHRQualification
Summary
| Module | Module | M1064 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.58 | % |
| Noise | Mean Noise | 305 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.82 | 99.54 | 0.23 | 61.1 | 189.7 | 0 | 0/0 | 0 | 3822 | 330 | 764 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.52 | 0.25 | 59.5 | 184.6 | 0 | 0/0 | 0 | 3812 | 341 | 952 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.59 | 0.23 | 56.5 | 176.0 | 0 | 0/0 | 0 | 3846 | 308 | 486 |
|
Chip 3
|
A
|
0 | 0 | 99.84 | 99.51 | 0.19 | 41.0 | 125.4 | 0 | 0/0 | 0 | 3866 | 292 | 344 |
|
Chip 4
|
A
|
0 | 0 | 99.83 | 99.63 | 0.15 | 32.1 | 97.5 | 0 | 0/0 | 0 | 3961 | 264 | 142 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.46 | 0.2 | 43.3 | 132.9 | 0 | 0/0 | 0 | 3872 | 320 | 664 |
|
Chip 6
|
A
|
0 | 0 | 99.85 | 99.48 | 0.2 | 35.6 | 109.5 | 0 | 0/0 | 0 | 3941 | 278 | 232 |
|
Chip 7
|
A
|
0 | 0 | 99.83 | 99.51 | 0.23 | 36.4 | 111.8 | 0 | 0/0 | 0 | 3945 | 290 | 286 |
|
Chip 8
|
A
|
1 | 0 | 99.82 | 100.01 | 0.19 | 38.6 | 118.1 | 0 | 0/0 | 0 | 3944 | 285 | 240 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.72 | 0.2 | 42.8 | 130.6 | 0 | 0/0 | 0 | 3666 | 309 | 485 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.47 | 0.23 | 48.5 | 148.0 | 0 | 0/0 | 0 | 3842 | 343 | 946 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.63 | 0.2 | 36.7 | 110.8 | 0 | 0/0 | 0 | 3933 | 293 | 416 |
|
Chip 12
|
A
|
0 | 0 | 99.79 | 99.51 | 0.13 | 34.4 | 105.2 | 0 | 0/0 | 0 | 3931 | 269 | 206 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.61 | 0.22 | 54.4 | 168.0 | 0 | 0/0 | 0 | 3872 | 296 | 367 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 99.60 | 0.28 | 57.1 | 176.9 | 0 | 0/0 | 0 | 3580 | 319 | 614 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.53 | 0.34 | 72.9 | 225.2 | 0 | 0/0 | 0 | 3818 | 338 | 909 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-27 | |
| TestTime | Test Time | 12:31 | |
| TestDuration | Duration | 0:56:10 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-11-g3f3decf on branch master
