Test Date: 2016-11-15 12:19
Analysis date: 2016-11-15 13:30
Analysis date: 2016-11-15 13:30
M1062 XRayHRQualification
Summary
| Module | Module | M1062 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 2 | |
| BumpBondingDefects | Bump Bonding Defects | 2 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.56 | % |
| Noise | Mean Noise | 361 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.83 | 99.54 | 0.33 | 71.2 | 216.4 | 0 | 0/0 | 0 | 3745 | 381 | 1483 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.56 | 0.34 | 70.0 | 211.0 | 0 | 0/0 | 0 | 3490 | 371 | 1388 |
|
Chip 2
|
A
|
0 | 0 | 99.80 | 99.54 | 0.33 | 85.1 | 256.8 | 0 | 0/0 | 0 | 3470 | 388 | 1631 |
|
Chip 3
|
A
|
1 | 0 | 99.83 | 99.61 | 0.26 | 56.4 | 170.2 | 1 | 0/0 | 0 | 3564 | 345 | 1044 |
|
Chip 4
|
A
|
0 | 0 | 99.83 | 99.56 | 0.22 | 49.1 | 147.2 | 0 | 0/0 | 0 | 3841 | 326 | 716 |
|
Chip 5
|
A
|
0 | 0 | 99.81 | 99.56 | 0.3 | 75.5 | 229.6 | 0 | 0/0 | 0 | 3739 | 367 | 1319 |
|
Chip 6
|
A
|
0 | 0 | 99.80 | 99.53 | 0.4 | 88.7 | 267.6 | 0 | 0/0 | 0 | 3686 | 400 | 1767 |
|
Chip 7
|
A
|
0 | 0 | 99.81 | 99.55 | 0.39 | 88.9 | 270.2 | 0 | 0/0 | 0 | 3718 | 397 | 1749 |
|
Chip 8
|
A
|
0 | 0 | 99.80 | 99.51 | 0.44 | 75.8 | 231.7 | 0 | 0/0 | 0 | 3695 | 384 | 1510 |
|
Chip 9
|
A
|
0 | 0 | 99.83 | 99.58 | 0.34 | 74.5 | 231.2 | 0 | 0/0 | 0 | 3721 | 382 | 1565 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.58 | 0.37 | 69.5 | 212.9 | 0 | 0/0 | 0 | 3760 | 365 | 1290 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.62 | 0.26 | 40.5 | 122.8 | 0 | 0/0 | 0 | 3863 | 302 | 488 |
|
Chip 12
|
A
|
1 | 0 | 99.83 | 99.58 | 0.14 | 38.1 | 114.5 | 1 | 0/0 | 0 | 3871 | 318 | 653 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.49 | 0.27 | 46.5 | 141.3 | 0 | 0/0 | 0 | 3851 | 315 | 552 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 99.54 | 0.26 | 60.1 | 185.0 | 0 | 0/0 | 0 | 3733 | 371 | 1354 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.58 | 0.28 | 67.9 | 207.2 | 0 | 0/0 | 0 | 3743 | 370 | 1343 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-15 | |
| TestTime | Test Time | 12:19 | |
| TestDuration | Duration | 0:56:55 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
