Test Date: 2016-10-27 11:28
Analysis date: 2016-10-27 12:36
Analysis date: 2016-10-27 12:36
M1061 XRayHRQualification
Summary
| Module | Module | M1061 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 3 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.83/99.43 | % |
| Noise | Mean Noise | 336 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.82 | 99.56 | 0.28 | 65.7 | 201.8 | 1 | 0/0 | 0 | 3749 | 334 | 842 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.59 | 0.24 | 57.5 | 173.3 | 0 | 0/0 | 0 | 3801 | 302 | 435 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.58 | 0.36 | 76.9 | 235.8 | 0 | 0/0 | 0 | 3730 | 361 | 1226 |
|
Chip 3
|
A
|
1 | 0 | 99.82 | 99.58 | 0.29 | 53.6 | 163.0 | 1 | 0/0 | 0 | 3783 | 338 | 899 |
|
Chip 4
|
A
|
1 | 0 | 99.81 | 99.52 | 0.31 | 44.0 | 133.1 | 1 | 0/0 | 0 | 3855 | 286 | 290 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.56 | 0.37 | 77.0 | 235.7 | 0 | 0/0 | 0 | 3778 | 358 | 1201 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 98.77 | 3.96 | 70.4 | 214.6 | 0 | 0/0 | 0 | 3775 | 344 | 1011 |
|
Chip 7
|
A
|
0 | 0 | 99.93 | 98.25 | 18.8 | 76.4 | 232.7 | 0 | 0/0 | 0 | 3812 | 326 | 731 |
|
Chip 8
|
A
|
0 | 0 | 99.82 | 99.57 | 0.41 | 87.8 | 267.5 | 0 | 0/0 | 0 | 3720 | 376 | 1476 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.55 | 0.3 | 76.2 | 232.8 | 0 | 0/0 | 0 | 3748 | 367 | 1322 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.56 | 0.4 | 85.4 | 262.7 | 0 | 0/0 | 0 | 3808 | 362 | 1266 |
|
Chip 11
|
A
|
0 | 0 | 99.83 | 99.52 | 0.33 | 50.6 | 154.2 | 0 | 0/0 | 0 | 3838 | 300 | 440 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.56 | 0.19 | 39.2 | 118.5 | 0 | 0/0 | 0 | 3879 | 287 | 326 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.59 | 0.29 | 69.0 | 211.3 | 0 | 0/0 | 0 | 3728 | 349 | 1080 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.56 | 0.37 | 73.3 | 223.8 | 0 | 0/0 | 0 | 6061 | 352 | 1152 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.58 | 0.3 | 69.9 | 213.1 | 0 | 0/0 | 0 | 3765 | 336 | 893 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-27 | |
| TestTime | Test Time | 11:28 | |
| TestDuration | Duration | 0:58:33 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 3039 | |
| nWarnings | # Warnings | 1836 | |
| channel_0_count | Channel 0 | 77 | |
| channel_1_count | Channel 1 | 2775 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 795 | |
| message_tokenchain_count | Token Chain Length | 1021 | |
| message_readback_count | Readback start marker | 1036 |
