Test Date: 2016-10-28 15:06
Analysis date: 2016-10-28 16:21
Analysis date: 2016-10-28 16:21
M1058 XRayHRQualification
Summary
| Module | Module | M1058 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.56 | % |
| Noise | Mean Noise | 322 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.82 | 99.47 | 0.32 | 63.2 | 190.3 | 1 | 0/0 | 0 | 3782 | 320 | 655 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.59 | 0.2 | 65.4 | 202.3 | 0 | 0/0 | 0 | 3787 | 321 | 676 |
|
Chip 2
|
A
|
0 | 0 | 99.81 | 99.59 | 0.33 | 66.8 | 201.7 | 0 | 0/0 | 0 | 3800 | 319 | 664 |
|
Chip 3
|
A
|
0 | 0 | 99.80 | 99.50 | 0.25 | 48.5 | 148.0 | 0 | 0/0 | 0 | 3716 | 294 | 359 |
|
Chip 4
|
A
|
0 | 0 | 99.83 | 99.57 | 0.23 | 53.4 | 163.5 | 0 | 0/0 | 0 | 3788 | 317 | 601 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.50 | 0.33 | 73.1 | 222.7 | 0 | 0/0 | 0 | 3725 | 337 | 910 |
|
Chip 6
|
A
|
0 | 0 | 99.83 | 99.59 | 0.33 | 80.6 | 242.3 | 0 | 0/0 | 0 | 3755 | 343 | 1014 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.59 | 0.33 | 79.1 | 244.4 | 0 | 0/0 | 0 | 3873 | 334 | 903 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.59 | 0.33 | 84.4 | 251.8 | 0 | 0/0 | 0 | 3799 | 327 | 803 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.54 | 0.37 | 85.8 | 266.6 | 0 | 0/0 | 0 | 3779 | 355 | 1202 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.51 | 0.26 | 83.3 | 249.6 | 0 | 0/0 | 0 | 3773 | 320 | 723 |
|
Chip 11
|
A
|
0 | 0 | 99.78 | 99.59 | 0.28 | 52.4 | 158.7 | 0 | 0/0 | 0 | 3571 | 312 | 578 |
|
Chip 12
|
A
|
0 | 0 | 99.83 | 99.53 | 0.27 | 51.1 | 152.8 | 0 | 0/0 | 0 | 3802 | 305 | 497 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 99.49 | 0.25 | 67.0 | 203.8 | 0 | 0/0 | 0 | 3818 | 304 | 503 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.67 | 0.27 | 65.3 | 197.0 | 0 | 0/0 | 0 | 3561 | 309 | 561 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.65 | 0.28 | 77.9 | 237.3 | 0 | 0/0 | 0 | 3558 | 343 | 1020 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-28 | |
| TestTime | Test Time | 15:06 | |
| TestDuration | Duration | 0:56:40 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-11-g3f3decf on branch master
