Test Date: 2016-10-27 16:59
Analysis date: 2016-10-27 18:07
Analysis date: 2016-10-27 18:07
M1057 XRayHRQualification
Summary
| Module | Module | M1057 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.57 | % |
| Noise | Mean Noise | 318 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.56 | 0.29 | 60.8 | 185.3 | 0 | 0/0 | 0 | 3840 | 304 | 439 |
|
Chip 1
|
A
|
0 | 0 | 99.81 | 99.57 | 0.31 | 65.7 | 200.0 | 0 | 0/0 | 0 | 3811 | 327 | 742 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.50 | 0.29 | 61.9 | 190.7 | 0 | 0/0 | 0 | 3797 | 326 | 742 |
|
Chip 3
|
A
|
0 | 0 | 99.82 | 99.57 | 0.24 | 45.9 | 139.9 | 0 | 0/0 | 0 | 3829 | 295 | 425 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.57 | 0.23 | 50.6 | 153.7 | 0 | 0/0 | 0 | 3792 | 312 | 576 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.60 | 0.25 | 69.7 | 218.2 | 0 | 0/0 | 0 | 3753 | 334 | 857 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 99.58 | 0.29 | 62.4 | 191.1 | 0 | 0/0 | 0 | 3839 | 309 | 533 |
|
Chip 7
|
A
|
1 | 0 | 99.83 | 99.63 | 0.26 | 68.9 | 212.8 | 1 | 0/0 | 0 | 3827 | 297 | 443 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.58 | 0.29 | 81.8 | 258.2 | 1 | 0/0 | 0 | 3756 | 338 | 981 |
|
Chip 9
|
A
|
0 | 0 | 99.83 | 99.62 | 0.31 | 67.9 | 209.8 | 0 | 0/0 | 0 | 3797 | 315 | 647 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.59 | 0.26 | 68.5 | 211.8 | 0 | 0/0 | 0 | 3840 | 316 | 618 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.57 | 0.23 | 48.4 | 146.7 | 0 | 0/0 | 0 | 3871 | 294 | 390 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 99.54 | 0.19 | 52.9 | 163.4 | 0 | 0/0 | 0 | 3800 | 316 | 666 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.59 | 0.29 | 70.5 | 223.2 | 0 | 0/0 | 0 | 3767 | 337 | 945 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 99.56 | 0.22 | 62.7 | 192.2 | 0 | 0/0 | 0 | 3774 | 319 | 690 |
|
Chip 15
|
A
|
0 | 0 | 99.81 | 99.55 | 0.32 | 74.3 | 228.5 | 5 | 0/0 | 0 | 3773 | 346 | 1006 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-27 | |
| TestTime | Test Time | 16:59 | |
| TestDuration | Duration | 0:57:26 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-11-g3f3decf on branch master
