Test Date: 2016-10-27 16:59
Analysis date: 2016-10-27 18:05
Analysis date: 2016-10-27 18:05
M1056 XRayHRQualification
Summary
| Module | Module | M1056 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 8 | |
| BumpBondingDefects | Bump Bonding Defects | 8 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.58 | % |
| Noise | Mean Noise | 304 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.81 | 99.55 | 0.32 | 70.9 | 221.1 | 1 | 0/0 | 0 | 3823 | 321 | 711 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.56 | 0.39 | 68.0 | 211.9 | 0 | 0/0 | 0 | 3790 | 333 | 815 |
|
Chip 2
|
A
|
1 | 0 | 99.83 | 99.57 | 0.3 | 66.6 | 206.8 | 1 | 0/0 | 0 | 3817 | 317 | 649 |
|
Chip 3
|
A
|
3 | 0 | 99.81 | 99.60 | 0.23 | 47.5 | 143.5 | 3 | 0/0 | 0 | 3831 | 290 | 310 |
|
Chip 4
|
A
|
1 | 0 | 99.77 | 99.37 | 0.34 | 39.4 | 119.7 | 1 | 0/0 | 0 | 3920 | 275 | 236 |
|
Chip 5
|
A
|
1 | 0 | 99.83 | 99.58 | 0.26 | 47.0 | 144.4 | 1 | 0/0 | 0 | 3605 | 302 | 432 |
|
Chip 6
|
A
|
0 | 0 | 99.80 | 99.43 | 0.31 | 48.6 | 148.8 | 0 | 0/0 | 0 | 3748 | 320 | 646 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.61 | 0.27 | 44.1 | 135.5 | 0 | 0/0 | 0 | 3914 | 290 | 311 |
|
Chip 8
|
A
|
0 | 0 | 99.82 | 99.51 | 0.24 | 48.2 | 148.3 | 0 | 0/0 | 0 | 3564 | 320 | 651 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.85 | 0.22 | 39.3 | 120.3 | 0 | 0/0 | 0 | 3876 | 280 | 238 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 99.61 | 0.2 | 53.3 | 165.0 | 0 | 0/0 | 0 | 3770 | 311 | 539 |
|
Chip 11
|
A
|
1 | 0 | 99.82 | 99.58 | 0.23 | 43.6 | 131.9 | 1 | 0/0 | 0 | 3828 | 289 | 370 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 99.63 | 0.21 | 43.0 | 130.0 | 0 | 0/0 | 0 | 3813 | 281 | 283 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.66 | 0.29 | 64.6 | 200.0 | 0 | 0/0 | 0 | 3790 | 307 | 469 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 99.60 | 0.27 | 70.0 | 216.1 | 0 | 0/0 | 0 | 3551 | 315 | 666 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.59 | 0.32 | 75.3 | 234.4 | 0 | 0/0 | 0 | 3778 | 317 | 682 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-27 | |
| TestTime | Test Time | 16:59 | |
| TestDuration | Duration | 0:57:26 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-11-g3f3decf on branch master
