Test Date: 2016-10-28 10:37
Analysis date: 2016-11-03 16:02
Analysis date: 2016-11-03 16:02
M1055 XRayHRQualification
| Comment | Comment | comment.txt: Address problem in part of a DC on C12 |
Summary
| Module | Module | M1055 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | C | |
| ROCGrades | ROC Grades A/B/C | 15/1/0 | |
| PixelDefects | Total Pixel Defects | 64 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 62 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.56 | % |
| Noise | Mean Noise | 322 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.82 | 99.57 | 0.33 | 71.0 | 221.7 | 1 | 0/0 | 0 | 3794 | 331 | 864 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.57 | 0.24 | 70.5 | 218.2 | 0 | 0/0 | 0 | 3781 | 341 | 985 |
|
Chip 2
|
A
|
0 | 0 | 99.81 | 99.55 | 0.33 | 64.3 | 199.8 | 0 | 0/0 | 0 | 3788 | 312 | 531 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.56 | 0.25 | 55.6 | 169.9 | 0 | 0/0 | 0 | 3792 | 340 | 906 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.52 | 0.24 | 42.5 | 131.1 | 0 | 0/0 | 0 | 3840 | 296 | 366 |
|
Chip 5
|
A
|
0 | 0 | 99.81 | 99.55 | 0.21 | 51.9 | 159.9 | 0 | 0/0 | 0 | 3799 | 329 | 779 |
|
Chip 6
|
A
|
0 | 0 | 99.83 | 99.70 | 0.13 | 44.7 | 138.0 | 0 | 0/0 | 0 | 3839 | 316 | 607 |
|
Chip 7
|
A
|
0 | 0 | 99.80 | 99.14 | 0.28 | 40.2 | 124.0 | 0 | 0/0 | 0 | 3894 | 299 | 382 |
|
Chip 8
|
A
|
0 | 0 | 99.82 | 99.60 | 0.23 | 47.6 | 147.4 | 0 | 0/0 | 0 | 3843 | 342 | 944 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.60 | 0.27 | 46.0 | 142.0 | 0 | 0/0 | 0 | 3846 | 302 | 450 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.60 | 0.19 | 59.8 | 186.9 | 0 | 0/0 | 0 | 3537 | 355 | 1150 |
|
Chip 11
|
A
|
1 | 0 | 99.82 | 99.68 | 0.14 | 39.8 | 121.6 | 0 | 0/0 | 0 | 3868 | 293 | 395 |
|
Chip 12
|
B
|
62 | 0 | 99.79 | 99.64 | 0.25 | 40.8 | 124.0 | 0 | 0/0 | 0 | 3894 | 306 | 497 |
|
Chip 13
|
A
|
0 | 0 | 99.80 | 99.50 | 0.44 | 66.9 | 211.7 | 0 | 0/0 | 0 | 3788 | 327 | 786 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 99.61 | 0.27 | 60.7 | 187.4 | 0 | 0/0 | 0 | 3817 | 320 | 638 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.54 | 0.28 | 75.6 | 239.9 | 0 | 0/0 | 0 | 3769 | 342 | 955 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-28 | |
| TestTime | Test Time | 10:37 | |
| TestDuration | Duration | 0:57:53 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 15 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
