Test Date: 2016-10-27 15:57
Analysis date: 2016-10-27 17:04
Analysis date: 2016-10-27 17:04
M1053 XRayHRQualification
Summary
| Module | Module | M1053 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 74 | |
| BumpBondingDefects | Bump Bonding Defects | 74 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 150/300 | 99.80/99.55 | % |
| Noise | Mean Noise | 337 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
13 | 0 | 99.82 | 99.56 | 0.34 | 70.5 | 222.7 | 15 | 0/0 | 0 | 3825 | 333 | 870 |
|
Chip 1
|
A
|
12 | 0 | 99.82 | 99.55 | 0.25 | 68.1 | 211.4 | 13 | 0/0 | 0 | 3592 | 347 | 1028 |
|
Chip 2
|
A
|
2 | 0 | 99.82 | 99.59 | 0.33 | 67.8 | 209.3 | 2 | 0/0 | 0 | 3767 | 360 | 1197 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.53 | 0.3 | 50.3 | 152.5 | 0 | 0/0 | 0 | 3799 | 327 | 758 |
|
Chip 4
|
A
|
0 | 0 | 99.80 | 99.53 | 0.3 | 46.0 | 140.1 | 0 | 0/0 | 0 | 3776 | 346 | 974 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.52 | 0.24 | 44.5 | 136.4 | 0 | 0/0 | 0 | 3859 | 337 | 844 |
|
Chip 6
|
A
|
0 | 0 | 99.79 | 99.55 | 0.25 | 45.3 | 139.1 | 0 | 0/0 | 0 | 3886 | 316 | 573 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.26 | 0.19 | 42.1 | 128.9 | 0 | 0/0 | 0 | 3870 | 305 | 443 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.80 | 0.24 | 43.6 | 134.8 | 0 | 0/0 | 0 | 3868 | 336 | 863 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.47 | 0.34 | 47.1 | 144.9 | 0 | 0/0 | 0 | 3617 | 368 | 1324 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.62 | 0.35 | 47.4 | 144.5 | 0 | 0/0 | 0 | 3832 | 343 | 891 |
|
Chip 11
|
A
|
0 | 0 | 99.78 | 99.59 | 0.19 | 37.6 | 114.2 | 0 | 0/0 | 0 | 3677 | 300 | 492 |
|
Chip 12
|
A
|
3 | 0 | 99.80 | 99.69 | 0.28 | 41.9 | 127.1 | 5 | 0/0 | 0 | 3871 | 315 | 559 |
|
Chip 13
|
A
|
5 | 0 | 99.80 | 99.43 | 0.36 | 60.2 | 185.0 | 7 | 0/0 | 0 | 3766 | 363 | 1250 |
|
Chip 14
|
A
|
31 | 0 | 99.81 | 99.55 | 0.31 | 66.8 | 205.2 | 32 | 0/0 | 0 | 3787 | 349 | 1020 |
|
Chip 15
|
C
|
8 | 0 | 99.75 | 99.51 | 2.07 | 68.4 | 213.8 | 9 | 0/0 | 1 | 3559 | 349 | 1061 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-27 | |
| TestTime | Test Time | 15:57 | |
| TestDuration | Duration | 0:58:12 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-11-g3f3decf on branch master
