Test Date: 2016-10-27 14:55
Analysis date: 2016-10-27 16:02
Analysis date: 2016-10-27 16:02
M1050 XRayHRQualification
Summary
| Module | Module | M1050 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 5 | |
| BumpBondingDefects | Bump Bonding Defects | 5 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.53 | % |
| Noise | Mean Noise | 310 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.55 | 0.24 | 66.1 | 207.3 | 0 | 0/0 | 0 | 3819 | 329 | 788 |
|
Chip 1
|
A
|
0 | 0 | 99.79 | 99.53 | 0.29 | 68.8 | 214.3 | 0 | 0/0 | 0 | 3784 | 342 | 988 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.59 | 0.27 | 56.6 | 177.1 | 0 | 0/0 | 0 | 3780 | 321 | 681 |
|
Chip 3
|
A
|
0 | 0 | 99.83 | 99.63 | 0.25 | 36.6 | 110.5 | 0 | 0/0 | 0 | 3930 | 271 | 163 |
|
Chip 4
|
A
|
0 | 0 | 99.83 | 99.29 | 0.21 | 32.6 | 99.0 | 0 | 0/0 | 0 | 3938 | 270 | 180 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.73 | 0.21 | 42.5 | 132.1 | 0 | 0/0 | 0 | 3654 | 301 | 431 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 99.55 | 0.15 | 37.9 | 116.4 | 0 | 0/0 | 0 | 3903 | 300 | 411 |
|
Chip 7
|
A
|
0 | 0 | 99.83 | 99.50 | 0.17 | 39.7 | 122.0 | 0 | 0/0 | 0 | 3890 | 309 | 490 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.54 | 0.19 | 39.5 | 121.7 | 0 | 0/0 | 0 | 3876 | 306 | 468 |
|
Chip 9
|
A
|
3 | 0 | 99.84 | 99.30 | 0.21 | 41.1 | 125.9 | 3 | 0/0 | 0 | 3832 | 298 | 399 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.60 | 0.26 | 46.1 | 142.9 | 0 | 0/0 | 0 | 3860 | 299 | 414 |
|
Chip 11
|
A
|
0 | 0 | 99.83 | 99.58 | 0.15 | 39.6 | 120.1 | 0 | 0/0 | 0 | 3840 | 312 | 536 |
|
Chip 12
|
A
|
1 | 0 | 99.82 | 99.43 | 0.19 | 38.2 | 115.7 | 1 | 0/0 | 0 | 3655 | 274 | 226 |
|
Chip 13
|
A
|
0 | 0 | 99.80 | 99.53 | 0.32 | 65.9 | 201.3 | 0 | 0/0 | 0 | 3749 | 335 | 894 |
|
Chip 14
|
A
|
1 | 0 | 99.82 | 99.54 | 0.38 | 67.1 | 208.5 | 1 | 0/0 | 0 | 3748 | 356 | 1181 |
|
Chip 15
|
A
|
0 | 0 | 99.81 | 99.55 | 0.32 | 69.1 | 216.2 | 0 | 0/0 | 0 | 3809 | 339 | 976 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-27 | |
| TestTime | Test Time | 14:55 | |
| TestDuration | Duration | 0:56:50 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
