Test Date: 2016-10-27 15:57
Analysis date: 2016-10-27 17:08
Analysis date: 2016-10-27 17:08
M1049 XRayHRQualification
Summary
| Module | Module | M1049 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 2 | |
| BumpBondingDefects | Bump Bonding Defects | 2 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.57 | % |
| Noise | Mean Noise | 325 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.80 | 99.68 | 0.24 | 63.4 | 190.0 | 1 | 0/0 | 0 | 3842 | 308 | 528 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.61 | 0.23 | 68.0 | 204.3 | 0 | 0/0 | 0 | 3742 | 327 | 780 |
|
Chip 2
|
A
|
0 | 0 | 99.84 | 99.58 | 0.27 | 68.4 | 207.1 | 0 | 0/0 | 0 | 3764 | 336 | 896 |
|
Chip 3
|
A
|
0 | 0 | 99.84 | 99.56 | 0.14 | 44.1 | 131.9 | 0 | 0/0 | 0 | 3853 | 284 | 290 |
|
Chip 4
|
A
|
0 | 0 | 99.85 | 99.60 | 0.17 | 50.4 | 154.1 | 1 | 0/0 | 0 | 3537 | 287 | 320 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.55 | 0.34 | 80.7 | 246.5 | 0 | 0/0 | 0 | 3738 | 353 | 1147 |
|
Chip 6
|
A
|
0 | 0 | 99.81 | 99.55 | 0.25 | 75.2 | 229.1 | 0 | 0/0 | 0 | 3750 | 340 | 931 |
|
Chip 7
|
A
|
0 | 0 | 99.80 | 99.56 | 0.41 | 91.5 | 276.7 | 0 | 0/0 | 0 | 3750 | 358 | 1263 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.56 | 0.33 | 84.5 | 264.4 | 0 | 0/0 | 0 | 3788 | 344 | 1037 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.53 | 0.39 | 87.8 | 266.2 | 0 | 0/0 | 0 | 3755 | 365 | 1318 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.55 | 0.33 | 80.8 | 247.8 | 0 | 0/0 | 0 | 3507 | 351 | 1140 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.57 | 0.22 | 51.5 | 156.6 | 0 | 0/0 | 0 | 3779 | 308 | 537 |
|
Chip 12
|
A
|
1 | 0 | 99.82 | 99.58 | 0.22 | 44.0 | 133.1 | 1 | 0/0 | 0 | 3823 | 290 | 352 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.59 | 0.29 | 71.4 | 215.7 | 0 | 0/0 | 0 | 3796 | 313 | 636 |
|
Chip 14
|
A
|
0 | 0 | 99.80 | 99.58 | 0.24 | 66.5 | 202.2 | 0 | 0/0 | 0 | 3738 | 313 | 647 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.55 | 0.19 | 73.2 | 227.2 | 0 | 0/0 | 0 | 3789 | 323 | 794 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-27 | |
| TestTime | Test Time | 15:57 | |
| TestDuration | Duration | 0:58:12 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
