Test Date: 2016-11-15 12:19
Analysis date: 2016-11-15 13:28
Analysis date: 2016-11-15 13:28
M1048 XRayHRQualification
Summary
| Module | Module | M1048 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 1 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.57 | % |
| Noise | Mean Noise | 314 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.52 | 0.38 | 70.0 | 217.7 | 0 | 0/0 | 0 | 3824 | 323 | 743 |
|
Chip 1
|
A
|
0 | 0 | 99.81 | 99.58 | 0.33 | 63.5 | 196.8 | 0 | 0/0 | 0 | 3801 | 328 | 806 |
|
Chip 2
|
A
|
0 | 0 | 99.78 | 99.51 | 0.43 | 70.8 | 221.7 | 0 | 0/0 | 0 | 3754 | 340 | 956 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.57 | 0.25 | 48.7 | 148.0 | 0 | 0/0 | 0 | 3832 | 321 | 672 |
|
Chip 4
|
A
|
0 | 0 | 99.80 | 99.54 | 0.23 | 42.0 | 128.7 | 0 | 0/0 | 0 | 3755 | 322 | 735 |
|
Chip 5
|
A
|
0 | 0 | 99.81 | 99.69 | 0.23 | 41.7 | 128.7 | 0 | 0/0 | 0 | 3897 | 289 | 320 |
|
Chip 6
|
A
|
0 | 0 | 99.83 | 99.60 | 0.23 | 42.0 | 128.9 | 0 | 0/0 | 0 | 3686 | 300 | 407 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.64 | 0.24 | 48.2 | 152.2 | 0 | 0/0 | 0 | 3743 | 323 | 717 |
|
Chip 8
|
A
|
0 | 0 | 99.80 | 99.43 | 0.27 | 45.4 | 140.0 | 0 | 0/0 | 0 | 3566 | 322 | 723 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.84 | 0.2 | 41.8 | 128.5 | 0 | 0/0 | 0 | 3888 | 295 | 420 |
|
Chip 10
|
A
|
0 | 0 | 99.79 | 99.46 | 0.27 | 53.0 | 162.2 | 0 | 0/0 | 0 | 3804 | 320 | 648 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.56 | 0.28 | 39.1 | 118.8 | 0 | 0/0 | 0 | 3623 | 295 | 400 |
|
Chip 12
|
A
|
0 | 0 | 99.80 | 99.56 | 0.32 | 41.7 | 127.1 | 0 | 0/0 | 0 | 3851 | 295 | 364 |
|
Chip 13
|
A
|
1 | 0 | 99.81 | 99.56 | 0.26 | 63.3 | 195.5 | 0 | 0/0 | 0 | 3777 | 323 | 711 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 99.55 | 0.27 | 62.0 | 193.9 | 0 | 0/0 | 0 | 3798 | 322 | 718 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.52 | 0.24 | 58.6 | 183.5 | 0 | 0/0 | 0 | 3804 | 301 | 439 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-15 | |
| TestTime | Test Time | 12:19 | |
| TestDuration | Duration | 0:56:55 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
v1.1.1-1-g54fa876 on branch master
